• Model NO.：SG18-3
• Trademark：Top brand
• Origin：China
• HS Code：8429209000
• Production Capacity：500,Month

EngineEngine modelCumiins 6BTAA5.9-C180Rated power/speed132   kW/2200 rpmEngine typeIn-line,   water-cooled, 4-cycle, direct injection, turbochargedNumber of cylinders6(102X120mm)Piston displacement5.9LMaximum torque/speed770   N·m/1500 rpmMinimum fuel consumption 206 g/kW·htravel speedTransmission   and torque converter: Electronic controlled transmission with 6 forward gears   and 3 reverse gears.Gear1st2nd3rd4th5th6thForward0~5.4   km/h0~9.3   km/h0~12.2   km/h0~20.7km/h0~25.6   km/h0~39.7   km/hReverse0~5.4   km/h0~12.2   km/h0~25.6   km/h   TRAVELTire   Type17.5-25PR12Steering systemMax.   steering angle of front wheel ±45°Max. tilting angle of front wheel±17°Max. oscillating angle of front axle±15°Steering angle of frame±25°Max. oscillating angle of rear axle±15°Min. turning radius7800 mmOperation weightOperating   weight (standard configuration)16200 kgFront axle load4800 kgRear axle load11400 kgBladeBlade   length 3660/3965   mmBlade height635 mmBlade rotational angle360°Cutting angle adjustment range44~91°Maximum cutting depth 500 mmCutting force per dozing 24.47 kN/mMaximum lift above ground 440 mmMaximum blade lateral extension (left/right) 1900/1950   mm
