• Model NO.：SPR200C-6
• Compaction Depth：25cm
• Engine Type：Diesel Engine
• Travel Speed：40cm,s
• Centrifugal Force：27KN
• Certification：EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008
• Condition：New
• Power：28,39kn
• Grade Ability：25 %
• Wheelbase：1728mm
• Emissions：Nr2
• Transport Package：Nude
• Specification：5200*2036*3275mm
• Trademark：SA--NY
• Origin：China
• HS Code：84294019
• Production Capacity：100 Sets,Month

Overview Product Description



Product Parameters



ItemSpecificationUnitEngine model4BTAA3.9-C125 Rated power93kWEmissionsNR2 Dimension(LxWxH)5200×2036×3275mmTotal  weight(Standard)20000kgTravel speed0~8km/hMax. gradeability25%Ground pressure200~480kPaMin. turning radius16850mmMin. ground clearance350mmCompaction width2085mmWheelbase3750mmSteering Angle30°Swing Distance50mmWater Tank500LFuel Tank160LHydraulic Oil Tank   100L

Item	Specification	Unit
Engine model	4BTAA3.9-C125
Rated power	93	kW
Emissions	NR2
Dimension(LxWxH)	5200×2036×3275	mm
Total  weight(Standard)	20000	kg
Travel speed	0~8	km/h
Max. gradeability	25	%
Ground pressure	200~480	kPa
Min. turning radius	16850	mm
Min. ground clearance	350	mm
Compaction width	2085	mm
Wheelbase	3750	mm
Steering Angle	30	°
Swing Distance	50	mm
Water Tank	500	L
Fuel Tank	160	L
Hydraulic Oil Tank	100	L
