• Model NO.：816C CLG816C
• Load and Unload Mode：Front Discharge
• Walking Mode：Wheeled
• Type：Small Loader
• Operating Weight (Kg)：5470 Kg
• Rated Bucket Capacity(M3)：0.8 M3
• Gross Power：55 Kw (75 HP) @ 2400 Rpm
• Net Power：50 Kw (68 HP) @ 2400 Rpm
• Total Cycle Time：8.2 S
• Tipping Load-Full Turn：3300 Kg
• Bucket Breakout Force：60 Kn
• Dump Clearance, Full Height Discharge：2420 mm
• Dump Reach, Full Height Discharge：790 mm
• Diesel Engine：Luochai Yt4a2 – 24
• Emissions：EPA Tier 2 , EU Stage II
• Cooling System：Charge Air Cooling
• Turning Radius, Outside of Tire：4185 mm
• Bucket Capacity：0.8-1.2 M3;
• Light Material：0.8-1.5 M3
• Transport Package：Nude Package
• Specification：5460 mm *1940 mm *2865 mm
• Trademark：Liugong
• Origin：China
• HS Code：8429590000
• Production Capacity：50000PCS,Year

Basic Info.

Model NO. 816C CLG816C Load and Unload Mode Front Discharge Walking Mode Wheeled Type Small Loader Operating Weight (Kg) 5470 Kg Rated Bucket Capacity(M3) 0.8 M3 Gross Power 55 Kw (75 HP) @ 2400 Rpm Net Power 50 Kw (68 HP) @ 2400 Rpm Total Cycle Time 8.2 S Tipping Load-Full Turn 3300 Kg Bucket Breakout Force 60 Kn Dump Clearance, Full Height Discharge 2420 mm Dump Reach, Full Height Discharge 790 mm Diesel Engine Luochai Yt4a2 – 24 Emissions EPA Tier 2 / EU Stage II Cooling System Charge Air Cooling Turning Radius, Outside of Tire 4185 mm Bucket Capacity 0.8-1.2 M3; Light Material 0.8-1.5 M3 Transport Package Nude Package Specification 5460 mm *1940 mm *2865 mm Trademark Liugong Origin China HS Code 8429590000 Production Capacity 50000PCS/Year

Product Description

                1 TON 0.8 m3 Mini Loader 816C CLG816C Cheap Price

• The turning radius is small and the steering is flexible; suitable for operating in tight spaces.
•
• Oscillating rear axle keeps four-wheel drive engaged for superior off-road mobility.
•
• One-stop maintenance: engine, fan, radiator and hydraulic hoses can be serviced from ground level.
•
• Optional multiple attachments include: multiple buckets, pallet fork, grapples, snow pusher blade and sweeper broom.
•

Technical Parameters of Hydraulic  Excavator


Operating weight	5470kg
Standard bucket	0.8 m³
Gross power	55 kW (75 hp) @ 2400 rpm
Net power	50 kW (68 hp) @ 2400 rpm
Rated load	1000 kg
Total cycle time	8.6s
Tipping load-full turn	4180 kg
Bucket breakout force	62 kN
Dump clearance, full height discharge	2417 mm
Dump reach, full height discharge	788 mm
Model	Luochai YT4A2 - 24
Emissions	EPA Tier 2 / EU Stage II
Cooling system	Charge air cooling
Length with bucket down	5457 mm
Width over tires	1940 mm
Cab height	2853 mm
Turning radius, outside of tire	4208 mm
General Purpose	0.8 m³
Light material	0.8-1.5 m³
