• Model NO.：SL20WN
• Load and Unload Mode：Front Discharge
• Walking Mode：Wheeled
• Type：Small Loader
• Bucket Capacity：1 M3
• Transport Package：7245X2482X3050 mm
• Specification：6200KG
• Trademark：SINOMADA
• Origin：China
• Production Capacity：50000PCS,Year



Overall width: 2078 mmTechnical specifications:Overall length: 5930 mmOverall height: 2850 mm GENERAL SPECIFICATIONSOperating weight6200 kgRelated loading2000 kgBucket capacity1.0 m3Maximum lifting force55 kNStatic tipping load (full turn)4000 kgDumping height2850 mmDumping reach865 mm ENGINEEngine modelLuotuo LR4B3-24TypeIn-line, water-cooled, 4-cylinder, direct injection, turbochargedRated power60 kWRated speed2400 rpmDisplacement4.48 LMaximum torque280 N·mMinimum fuel consumption242 g/kW·h AXLES AND FINAL DRIVESDRIVE SYSTEMFour-wheel driveGradeability30°Maximum traction54 kNBRAKE SYSTEM:Service brakesAir over oil four-wheel dual-loop disc brake systemParking brakeAutomatically air-cut brake, disc brakeSTEERING SYSTEM:TypeArticulated type, full-hydraulic power steeringMaximum steering angle35° each directionThe center of outside tire4664 mmThe center of outside bucket5090 mmTIRESType23.5-25 16PRPattern levelL3
