Oriemac Grader 170HP Stg170c Gr165 Sg16-3 Clg4165 Sem919 140K 717h RC Motor Grader for Sale
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- After-sales Service：Yes
- Warranty：I Year
- Certification：CE
- Condition：New
- Application：Railway, Mine, Farmland, Highway
- Transmission：Hydraulic
Base Info
- Model NO.：STG170C-8
- Walking Mode：Wheeled
- Type：Small Grader
- Transport Package：Nude
- Specification：8580*2740*3310mm
- Trademark：Oriemac
- Origin：China
- HS Code：8429521200
- Production Capacity：350units,Month
Description
Model
STG140C-8S
STG170C-8S
STG190C-8S
Engine Model
6BTA5.9-C150-
WP6G180E330
WP6G200E330
Rated Power
112kW
132.5kW
147kW
Peak Torque
655NM
750NM
900NM
Overall Dimensions
8765×2460×3310mm
8775×2740×3348mm
9265×2740×3348mm
Operating Weight
13000kg
14730kg
15800kg
Forward Speed
5/8/12/19/28/41km/h
5/8/10/18/26/40km/h
6/10/13/21/27/42km/h
Reverse Speed
5/12/28km/h
5/10/26km/h
6/13/27km/h
Min. Turning Radius
/m
/m
/m
Length of Blade
3660 (12ft)mm
3660 (12ft)mm
3660 (12ft)mm
Height of Blade
620mm
620mm
620mm
Max. Lift Above Ground
420mm
480mm
480mm
Max. Depth of Cut
630mm
630mm
630mm
