XCMG Official Hydraulic Excavator Xe150wb 15 Ton Bucket Wheel Excavator
Xuzhou Construction Machinery Group Co., Ltd.- After-sales Service：Overseas Service Center Available
- Warranty：1year
- Type：Wheel Excavator
- Usage：Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
- Bucket Capacity：>1.5m³
- Size：Large-Scale
Base Info
- Model NO.：XE150WB
- Certification：CE, ISO9001: 2000
- Condition：New
- Transport Package：Comply with Export Packaging Requirements
- Specification：ISO
- Trademark：XCMG
- Origin：Xuzhou, Jiangsu, China
- HS Code：87059091
- Production Capacity：1000,Year
Description
Overview
Product Description
Max digging height:8190mm
Main configuration
Cummins QSB4.5 engine 104kw
Hydraulic system
XE150WB plays an important role in the aspects of airport, port, oil field, urban construction, irrigation and water conservancy and rapid repair, and brings rich value returns for customers.
XE150WB wheeled hydraulic excavator is powerful, flexible and exquisite enough to cope with a variety of working conditions. The appearance size of the machine complies with road regulations and transportation requirements.
As a model featuring sufficient flexibility, high fuel efficiency and operation reliability in accordance with the North America and Euro-III emission standards,
This machine has used a new generation of independent researched and developed controllers as well as a low-noise pump and especially considered the matching between the engine and the low-speed load to make full use of the engine power, improve the working efficiency and effectively reduce the fuel consumption. The reliability during heavy-load operations can be satisfied by virtue of its lightweight chassis with high rigidity and strengthened key parts.
Product Parameters Unit Parameters Operating weight Kg 15318 Bucket capacity M³ 0.58 Engine model / QSB4.5 Engine Output power of engine Kw/r/min 104/2000 Max.torque/engine N.m 586 Displacement L 4.5 Fuel tank capacity L 250 Rated flow of main pump L/min 2x160 Pressure of main safety valve Mpa 31.4/34.3 performance parameter Hydraulic tank capacity L 135 Slewing speed r/min 13.7 Digging capacity of tcuket KN 60 Digging capacity of tcuket rod KN 65 Min.turning radius mm 6500 Travel speed Km/h 45 Gradient capability % 70 A Total length mm 6482 B Total width mm 2552 C Total heigth mm 3158 Working scope Counterweight ground clearance mm 1230 Min.ground clearance mm 359 Min.tail swing radius mm 2300 Wheelbase mm 2800 Track gauge mm 1920 Total width of chassis mm 2495 Distance between front axle and turning center mm 1700 Hood height mm 2430 The maximum digging depth of dozer mm 112 Dozer (width / height) mm 2495x564 A Max.digging height mm 8296 Working scope B Max.unloading height mm 8085 C Max.digging depth mm 9150 D Digging depth at the range of 8feets horizontally mm 6684 E Max.vertical digging depth mm 5040 F Max.digging radius mm 4825 G Max.swing height mm 515
Company Profile
FAQ
1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC,
3: What about the delivery time?
A: 30 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs.
Main parameters:
Bucket capacity:0.58CBMMax digging height:8190mm
Main configuration
Cummins QSB4.5 engine 104kw
Hydraulic system
XE150WB plays an important role in the aspects of airport, port, oil field, urban construction, irrigation and water conservancy and rapid repair, and brings rich value returns for customers.
XE150WB wheeled hydraulic excavator is powerful, flexible and exquisite enough to cope with a variety of working conditions. The appearance size of the machine complies with road regulations and transportation requirements.
As a model featuring sufficient flexibility, high fuel efficiency and operation reliability in accordance with the North America and Euro-III emission standards,
This machine has used a new generation of independent researched and developed controllers as well as a low-noise pump and especially considered the matching between the engine and the low-speed load to make full use of the engine power, improve the working efficiency and effectively reduce the fuel consumption. The reliability during heavy-load operations can be satisfied by virtue of its lightweight chassis with high rigidity and strengthened key parts.
Product Parameters
Company Profile
FAQ1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC,
3: What about the delivery time?
A: 30 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs.
