• Model NO.：PY-U600
• Rubber Track Width：148mm
• Color：Black
• Weight：53.5kg
• Sprocket Diameter：190mm
• Load-Bearig：300kg
• Warranty：12 Months Under Normal Use
• Transport Package：Bare Packing or Wooden Pallet
• Specification：795*600*280mm
• Trademark：No Marks or As Buyer′s Requests
• Origin：Shanghaichina
• HS Code：8431499900
• Production Capacity：2set,Month

Basic Info.

Model NO. PY-U600 Rubber Track Width 148mm Color Black Weight 53.5kg Sprocket Diameter 190mm Load-Bearig 300kg Warranty 12 Months Under Normal Use Transport Package Bare Packing or Wooden Pallet Specification 795*600*280mm Trademark No Marks or As Buyer′s Requests Origin Shanghaichina HS Code 8431499900 Production Capacity 2set/Month

Product Description

The feature of rubber tracks:

(1). Less round damage

       Rubber tracks cause less damage to roads than steel tracks, and less rutting of soft ground than either steel tracks of wheel products.

(2). Low noise

      A benefit to equipment operating in congested areas, rubber track products less noise than steel tracks.

(3). High speed

       Rubber track permit machines to travel at a higher speed than steel tracks.

(4). Less vibration

       Rubber tracks insulate machine and operator from vibration, extending the machine's lifetime and lowering operate fatigue.

(5). Low ground pressure

       The ground pressure of rubber tracks equipped machinery can be fairly low, about 0.14-2.30 kg/ cmm , a major reason for its use on the wet and soft terrain .

(6). Superior traction



The added traction of rubber, track vehicles permits them to pull twice the load of wheel vehicles of the sane weight.

All the size(except the track width) can be adjusted

Application: moving platform and other vehicle

Warranty:Guarantee one year under normal use

Application and Features:

1. Suitable for the small wheelchair.

2. Can load weight about500-800KG

3. Length can be adjusted.

4. Sprocket is available.

Characteristics of rubber track:

1). Less damage to the ground surface

2). Low noise

3). High running speed

4). Less vibration;

5). Low ground contack specific pressure

6). High tractive force

7). Light weight

8). Easy to change

Length	Width	Height	Drive Wheel Diameter	Track Width	Weight	Load bearing	Speed
795mm	600mm	280mm	190mm	148mm	53.5kg	300kg	-------
