Concrete Vibrator with Diesel Engine (170F)

Ningbo Ace Machinery Co., Ltd.
  • Type：Concrete Vibrator
  • Shotcrete Type：Semi-Dry
  • Machining Process：Assembly
  • Structure：Cylinder Type
  • Productivity：75m²,h
  • Vibrating Amplitude：1.2mm

Base Info

  • Model NO.：ZXD
  • Certification：ISO9001: 2000, CE
  • Condition：New
  • Color：Yellow
  • Product Name：Concrete Vibrator with Diesel Engine
  • Engine Model：170f
  • Power：4.0HP
  • Coupling：Japanese Type
  • N.W.：34kgs
  • Packing Size：51*39*51cm
  • Transport Package：Carton
  • Specification：4.0HP
  • Trademark：KZW
  • Origin：China
  • HS Code：84306100
  • Production Capacity：1000 PCS,Year

Description

ItemDiesel engine 170FEngine type4-stroke 25° Single-cylinder with Air-cooledBorex stroke70*55mmDisplacement211cm3Max power 4hp/3600rpmRecommded power using3.67hp/ 3000rpmFuel Tank capacity2.5LFuel consumption220g/hp-hr (300g/kwh)packing size51*39*51cmN..W/G.W.34kgs/36kgsMatched vibrator shaft (They all can work with below vibrator shaft)        ModelZX-32 /  6MZX-38 /  6MZX-45 / 6MZX-60 /  6MZX-70 /  6MOut Dia of hose30MM30MM32MM36MM36MMOut Dia of shaft10MM10MM12MM13MM13MMpacking size75*75*5.5cm75*75*5.5cm75*75*5.5cm75*75*5.5cm75*75*5.5cmN..W/G.W.11.8kgs/12.8kgs12.3kg /13.3kgs16.2kgs/17.2kgs21kgs/22kgs21kgs/22kgs

Concrete Vibrator with Diesel Engine (170F)
