Strong 1.6 Ton Front Wheel Loader (HQ916G) for Sale
Weifang Haiqin Top Machinery Co., Ltd.- After-sales Service：24 Hours Every Day of Technology and Parts Service
- Warranty：12 Months
- Type：Wheel Excavator
- Usage：Earth Moving,Building, Construction
- Bucket：Shovel
- Transmission：Hydraulic Transmission
Base Info
- Model NO.：HQ916G
- Drive Type：Internal Combustion Drive
- Bucket Capacity：0.5~1.0m³
- Size：Small-Scale
- Certification：CE, ISO9001: 2000, SGS,Rops&Fops
- Condition：New
- Appearance：New Design
- Loading Weight：1600kg
- Engine：Euro III
- Transport Package：3 Units in One Hq40 Container
- Specification：CE, ISO, SGS, ROP&FOPS
- Trademark：Haiqin
- Origin：Shandong, China
- HS Code：84295100
- Production Capacity：9000 Units , Year
Description
Specifications of HQ916G wheel loader :1,Engine Details Model: XINCHAI 498BT ( Euro III and EPA ) Engine type: In-line arrangement, water-cooled, four-cycle diesel Engine Rated Power: 37kw Rated Speed: 2400 r/p. Min (rpm) Fuel Consumption ratio in standard working condition: 230g/kw. H 2,Transmission System Type: Fixed-spindle Power shift Shift gear control oil pressure: 1.2~1.5MPa Rated input speed: 2500 (rpm) 3,Bucket Bucket Capacity: 0.8m3 Bucket width: 1800mm Bucket type: Heavy-duty bolt on teeth Max. Breakout Force: 42KN Rated Load: 1600kg Operating Weight: 4150kg 4,Overall Dimensions Overall Length (Bucket on ground position): 5300mm Overall Height : (a) Ground to Cab Top: 2750mm (b) Dumping Height: 2700mm (c) Overall Width: 1800mm 5, Operating Specifications Steering System: Articulated Frame with hydraulic power steering Min Turning Radius: 4500mm Driving System: Hydraulic converter 6,Brake System Service Brake: Four Wheel Hydraulic spread-shoed brake Parking Brake: Hand operated 7,Tyre Model: 20.5/70-16 8,Wheelbase : 2100mm 9,Track: 1500mm
