• Model NO.：SE150
• Drive Type：Diesel
• Bucket Capacity：0.5~1.0m³
• Size：Medium-Sized
• Certification：CE, ISO9001: 2000
• Condition：New
• Product Name：Se150
• Maximum Digging Height (mm)：8670
• Maximum Dumping Height (mm)：6210
• Model：Qsf3.8t (China-III)
• Bucket Arm Digging Force (Kn)：70
• Displacement (L)：3.76
• Rated Power (Kw/Rpm)：86,2200
• Type of Hydraulic Pump：Variable Displacement Duplex Plunger Pump
• Brake Type：Mechanically Applied
• Maximum Swing Speed (R/Min)：11.3
• Transport Package：Nude
• Specification：5855mm*1880mm*2060mm
• Trademark：Famous
• Origin：China
• HS Code：84295212
• Production Capacity：2000

Comparative itemSE150 (Standard version)Overall dimensions Overall length (mm)7860Ground length (During transport) (mm)4390Overall height (To the top of boom) (mm)2860Overall width (mm)2645Overall height (To top of cab) (mm)2855Ground clearance of counterweight (mm)915Minimum ground clearance (mm)425Tail turning radius (mm)2380Track length (mm)3645Track gauge (mm)2000Track width (mm)2500Standard track shoe width (mm)500Turntable width (mm)2645Distance from slewing center to tail (mm)2375Working range Maximum digging height (mm)8670Maximum dumping height (mm)6210Maximum digging depth (mm)5490Maximum vertical digging depth (mm)4625Maximum digging distance (mm)8325Maximum digging distance at ground level (mm)8195Working device minimum turning radius (mm)2395Maximum lifting height of bulldozer blade (mm)-Maximum digging depth of bulldozer blade (mm)-Engine ModelQSF3.8T (China-III)Type 4-cylinder, high pressure common rail, and water-cooled and turbochargedDisplacement (L)3.76Rated power (kW/rpm)86/2200Hydraulic system Type of hydraulic pumpVariable displacement duplex plunger pumpRated working flow (L/min)2x130Bucket Bucket capacity (m³)0.65Swing system Maximum swing speed (r/min)11.3Brake typeMechanically applied and pressure releasedDigging force Bucket arm digging force (KN)70Bucket digging force (KN)97Operating weight and ground pressure Operating weight (kg)14500Ground pressure (kPa)43.8Traveling system Traveling motorAxial variable displacement plunger motorTraveling speed (km/h)3.25/5.2Traction force (KN)118Gradeability70%(35°)Tank capacity Fuel tank capacity (L)220Cooling system (L)20Engine oil capacity (L)12Hydraulic oil tank/system capacity (L)177/205
