Hot Zoomlion Bulldozer Machine Zd320-3 35 Tons Popular to Brazil
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：Provided
- Warranty：1 Year
- Type：Universal Type
- Transmission：Hydraulic Transmission
- Walking Mode：Crawler
- Load and Unload Method：Front Discharge
Base Info
- Model NO.：ZD320-3
- Engine Power：147~515kw
- Certification：CE, ISO9001: 2000
- Condition：New
- Color：Orange
- Transport Package：Nude
- Specification：35ton
- Trademark：SINOMADA
- Origin：China
- HS Code：8429521200
- Production Capacity：10,Month
Description
Key Technical ParameterBlade type - Small Semi-U Blade Small Semi-U Blade Working mass kg 35044 35100 Blade capacity m3 11.6 11.6 Engine model - NTA855-C360 NTA855-C360 Rated power/Slewing speed kW/rpm 257 257 Max. torque N.m/rpm 1509/1400 1412/1400 Min. fuel consumption g/kW.h 242 242 Max. Drawbar pull Kn 302 355 Ground pressure kPa 106 106 Gradeability° ° 30 30 Traveling speed of forward km/h 3.6/6.6/11.5 3.7/6.8/11.8 Traveling speed of Reverse km/h 4.4/7.8/13.5 4.5/8.2/13.7 Basic Technical Parameter Height of cab mm 3600 3570 Height of ROPS mm 3687 3673 Ground contact length mm 3150 3150 Height of blade mm 1705 1553 Track center distance mm 2140 2140 Height of grouser mm 80 80 Track shoe width mm 560 560 Operating Range Max. lift height of dozer mm 1560 1560 Max. drop depth mm 560 560 Max. lift height of ripper mm single-shank 960
multi-shank 890 890 Max. ripping depth of ripper mm single-shank 1235
multi-shank835 835 Max. tilt mm 1000 1000
multi-shank 890
multi-shank835
