• Certification：CE, ISO9001: 2000
• Condition：New
• Operating Weight：25500kg
• Maximum Digging Height：9662mm
• Maximum Digging Depth：6895mm
• Max Digging Radius：10240mm
• Rated Speed：5.9,4.0km,H
• Color：Yellow
• Ground Pressure：50.1kpa
• Max.Traction：194kn
• Rated Flow of Main Pump：2*256L,Min
• Pressure of Traveling System：34.3MPa
• Transport Package：Comply with Export Packaging Requirements
• Trademark：XCMG
• Origin：Jiangsu, China
• HS Code：84295212
• Production Capacity：1000,Year

  UnitParametersModelOperating weightkg25500Bucket capacitym³1.05-1.25EngineEngine model/ISUZU CC-68G1TRP-05Direct injection/√4×strokes/√Water cooling/√Turbocharging/√A/A Air-air intercool/√Cylinders/6Output power of engineKw/rpm135.2/2150Max.torque/engineN.m/rpm637/1800DisplacementL6.494Mian pertormanceTravel speedkm/h5.9/4.0Slewing speedr/min11.3Gradient capability°≤35°Ground pressurekPa50.1Digging capacity of tcuketkN179Digging capacity of tcuket rodkN125Max.tractionkN194Hydraulic systemMain pump/Tow plunger pumpsRated flow of main pumpL/min2×256Pressure of main safety valveMpa34.3/37Pressure of traveling systemMpa34.3Pressure of swing systemMpa28Pressure of pilot systemMpa3.9Oil volumeFuel tank capacityL400Hydraulic tank capacityL240Engine oil volumL25Apperance sizeA Total lengthmm10160B Total widthmm3190C Total heigthmm3000D Width of rotary tablemm2830E Length of trackmm4640F Total width of chassismm3190G Width of trackmm600H Wheelbase of trackmm3742I Track gaugemm2590J Counterweight ground clearancemm1100K Min.ground clearancemm485L Min.tail swing radiusmm2985Working scopeA Max.digging heightmm9662B Max.unloading heightmm6810C Max.digging depthmm6895D Digging depth at the range of 8 feets horizontallymm6750E Max.vertical digging depthmm5480F Max.digging radiusmm10240G Max.swing heightmm3850Standard configurationBoom lengthmm6000Length of bucket rodmm2960Bucket capacitym³1.2Optional counfigurationLength of bucket rodmm2500Bucket capacitym³1.25Rock bucket  1.05Earthmovingbucket













FAQ

1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted

2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC,

3: What about the delivery time?
A: 30 days after receiving the deposit.

4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.

5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs.
