• Model NO.：LYZY2500
• Productivity：25m²,h
• Feeding Height：1390mm
• Vibrating Amplitude：2.2mm
• Certification：ISO9001: 2000, CE, SGS,Rops&Fops
• Condition：New
• Color：According to Buyers
• Size：6030X2180X2250mm
• Engine Power：55kw
• Transport Package：Nude Package
• Specification：ISO, SGS
• Trademark：Haiqin
• Origin：Shandong, China
• HS Code：87054000
• Production Capacity：8000 Units , Year

Basic Info.

Model NO. LYZY2500 Productivity 25m²/h Feeding Height 1390mm Vibrating Amplitude 2.2mm Certification ISO9001: 2000, CE, SGS,Rops&Fops Condition New Color According to Buyers Size 6030X2180X2250mm Engine Power 55kw Transport Package Nude Package Specification ISO, SGS Trademark Haiqin Origin Shandong, China HS Code 87054000 Production Capacity 8000 Units / Year

Product Description

Maximum mixing capacity m3: 2.5
Mixing drum volume m3: 2.8
Angle of inclination 0: 16
Rotational speed r/min: 0-14
Rotational direction Feedstock: Clockwise Ejection of compact: Anticlockwise
Mixing drum vanes Two sets helical vanes and assisted vanes
The slumps of concrete mm: 70-260
Hydraulic transmission system
Oil pump: CBF-32
Motor model: BMS-100
Reduction box model/speed ratio: HJ220
Water supply system
Water form Its own water supply mechanism
Water tank volume: L 400
Chasis and Engine parameters and specifications
Engine model: YC4D85Z-T21
Form Four-stroke direct injection water cooling diesel engine
Air Cylinder: 4
Displacement L: 4.214
Rated power kw/r/min: 60/2400
Maximum torque N. M/r/min: 265/1600-1800
Maximum travelling speed km/h: 26
Minimum diameter of turning circle M: 8
Gradeability % 2: 4
Tyre: 8.25-16
Driving form: 4*4
Carload equipped weight kg: 5850
Maximum loading weight Kg: 5500
Total weight in travel kg: 11500
Carload overall dimension(L/W/H) mm: 6200x2350x3000
