• Model NO.：SY-27T
• Usage：Universal Type
• Scraper Type：Pull Scraper
• Load and Unload Method：Front Discharge
• Engine Power：147~515kw
• Color：Yellow
• Transport Package：in Nude
• Specification：ISO
• Trademark：SUNY
• Origin：China
• HS Code：84295100
• Production Capacity：1000 Units

Performance
1
rated load
27T
2
overall weight
28T
3
maximum tractive force
200KN
4
maximum breakout force
200KN
5
overall dimension (L×W×H)
8880×3100×3500mm
6
maximum grade ability
25-30°C
7
maximum dump height
2700mm
8
maximum dump reach
2220mm
9
minimum turning radius
4590mm
Engine
11
model
Weichai Steyr DHD10G0353
12
type
lnline water cooling dry cylinder injection
13
No. of cylinder-bore/stroke
6-126×130mm
14
rated power
175kw--2200r/min
15
maximum torque
843N.m
16
min fuel-consume ratio
≤220g/kw.h

Transmission system
17
torque converter
Twin turbo four components
18
gearbox mode(WG180)
Planectary
19
gear shift
2 forward shift
1 reverse shift
20
maximum speed
38km/h
Drive axles
21
:main reducing spiral
bevel gear grade 1reduction
22
decelerating mode
planetary reduction,grade 1
23
wheel base (mm)
3350mm
24
wheel tread
2250mm
25
minimum ground clearance
450mm
Hydraulic system
26
system working pressure
18MPa
27
boom lifting time
7.7s
28
total time
15s
29
fuel tank capacity
300L
30
function of leveling automatically
yes

Brake system
31
service brake
air over hydraulic disc brake on 4 wheels
32
parking brake
manual parking brake

Tyre
33
type specification
26.5-25
34
front tyre pressure
0.55Mpa
35
rear tyre pressure
0.55Mpa
