• Model NO.：SR23MR
• Compaction Depth：40cm
• Engine Type：Diesel Engine
• Travel Speed：4.37,6.82km,H
• Centrifugal Force：82,40
• Certification：CE, ISO 9001:2000
• Condition：New
• Operating Weight (Kg)：23000
• Exciting Force (Kn)：82,40
• Vibration Frequency (Hz)：42,48
• Ground Pressure (Kpa)：100-220
• Gradeability (%)：100
• Engine Model：Wp10
• Rated Power/Rated Speed (Kw/Rpm)：162,2200
• Wheelbase (mm)：3500
• Fuel Tank (L)：400
• Compacting Width(mm)：3090
• Transport Package：Container,RO-RO
• Specification：7360*3200*3640mm
• Trademark：SHANTUI
• Origin：China
• HS Code：8429401900
• Production Capacity：100units,Month

Basic Info.

Model NO. SR23MR Compaction Depth 40cm Engine Type Diesel Engine Travel Speed 4.37/6.82km/H Centrifugal Force 82/40 Certification CE, ISO 9001:2000 Condition New Operating Weight (Kg) 23000 Exciting Force (Kn) 82/40 Vibration Frequency (Hz) 42/48 Ground Pressure (Kpa) 100-220 Gradeability (%) 100 Engine Model Wp10 Rated Power/Rated Speed (Kw/Rpm) 162/2200 Wheelbase (mm) 3500 Fuel Tank (L) 400 Compacting Width(mm) 3090 Transport Package Container/RO-RO Specification 7360*3200*3640mm Trademark SHANTUI Origin China HS Code 8429401900 Production Capacity 100units/Month

Product Description

23Ton SHANTUI Vibratory Road Roller in the StockProduct discription
Working performance

The installed Weichai China-III electronic control engine can maintain the machine under best working status with strong power to ensure the compacting quality and high efficiency and energy-saving.

The hydro-mechanically driven power drive system is professionally designed and precisely manufactured specially for severe waste treatment environment and provide higher productivity.

The high capacity blade can bulldoze the waste during the compacting to improve the operating efficiency.

The professionally designed compacting drum guarantees the effective compacting and crushing of the waste. The compacting teeth are made of corrosion-resistant and wear-resistant material to prolong the life of compacting drum.

PARAMETER

Parameter name	SR23MR (Standard version)
Performance parameters
Operating weight (Kg)	23000
Exciting force (KN)	-
Vibration frequency (Hz)	-
Nominal amplitude (mm)	-
Ground pressure (KPa)	-
Gradeability (%)	-
Engine
Engine model	WP10
Rated power/rated speed (kW/rpm)	162/2200
Overall dimensions
Overall dimensions of machine (mm)	7360*3200*3640
Driving performance
Forward speed (km/h)	4.37/6.82/10
Reversing speed (km/h)	4.37/6.82
Chassis System
Wheelbase (mm)	-
Tank capacity
Fuel tank (L)	400
Working device
Compacting width(mm)	3090
