China 35ton Heavy Duty Pneumatic Rubber Tire Road Roller Supplier
Sinoway Industrial (Shanghai) Co., Ltd.- Type：Road Roller
- Working Method：Wheeled
- Axle：Biaxial Dual-Drum
- Grinding Wheel Type：Tire Grind
- Compaction Depth：40cm
- Engine Type：Diesel Engine
Base Info
- Model NO.：SWP3035H
- Travel Speed：40cm,s
- Certification：CE, ISO 9001:2000, ISO 9001:2008, ISO14001
- Condition：New
- Operating Weight：35000 Kg
- Transmission：Hydraulic
- Tire Size：11.00-20
- Compaction Width：3065 mm
- Rated Power：147kw
- Engine Make：Sdec
- Warranty：One Year
- Transport Package：Nude
- Specification：ISO
- Trademark：SINOWAY
- Origin：China
- HS Code：84314990
- Production Capacity：500 Unit Per Year
Description
EngineMake SC8D200 Type Six-cylinder,water-cooled turbocharged,mechanical injection Rated power 147kw Rated speed 2000rpm Transmission System Type Hydro-static Gradeability (with ballast) 20% Travelling speed Forward/Reverse I 0 - 6km/h Forward / Reverse II 0 - 11km/h Travelling pump Piston pump Travelling motor Piston motor Axle and Tyre Single tire load (F/R) 3180kg Tyre number (F+R) 5+6 Tyre size 11.00-20 Main Technical Specification Operating weight with ballast 35000Kg Operating weight without ballast 30000kg Average ground pressure 0.4 - 0.53MPa Tyre pressure 0.25 - 0.63MPa Compacting width 3065mm Vertical oscillation ± 100mm Wheel overlap 50mm Steering angle 35° Oscillating angle of front tires 4° Steering System Type Hydraulic steering Working pressure 13MPa Steering cylinder 90 x 50 x 260mm Min. steering radius 9000mm Braking System Service brake Hydraulic brake Parking brake Mechanical apply, hydraulic release Service Capacities Hydraulic tank 100L Gear box 10L Fuel tank 350L Engine crank case 16L Water tank 900L Dimensions Overall length 5524mm Overall width 3065mm Overall height 3270mm Wheelbase 4400mm Ground clearance 325mm Electrical System System voltage 24 V
