• Model NO.：XE215C
• Size：Large-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Operating Weight：21.5 Ton
• Maximum Digging Height：9640mm
• Maximum Digging Depth：6655mm
• Engine：Isuzu Bb-6bg1trp
• Max. Digging Reach：9925mm
• Transport Package：Main Machine Nude, Attached Parts Into Export Case
• Specification：CE, ISO9001
• Origin：Jiangsu, China
• HS Code：84295212
• Production Capacity：500 Set,Sets , Month

Model
 XE215C
 Bucket capacity
 m³
 0.91
 Standard bucket width
 mm

 Operating weight
 kg
 2,1500
 Dimension (in transportation)
 Overall length
 mm
 9,520
 Overall width
 mm
 2,990
 Overall height
 mm
 2,985
 Min. ground clearance
 mm
 485
 Engine
 Model
 ISUZU BB-6BG1TRP
 Total displacement
 L
 6.494
 Rated output power
 KW/rpm
 106.5/1950
 Digging performance
 Max. digging height
 mm
 9,640
 Max. dumping height
 mm
 6,800
 Max. digging depth
 mm
 6,655
 Max. vertical digging depth
 mm
 5,695
 Max. digging radius
 mm
 9,925
 Boom deflection angle: left/right
 °

 Min. slew radius
 mm
 3,530
 Min. rear slew radius
 mm
 2,750
 Bucket digging force
 kn
 138
 Track type
 Steel
 Track width
 mm
 600
 Travel system
 Track overall length
 mm
 4,255
 Wheel base
 mm
 3,462
 Track gauge
 mm
 2,390
 Travel speed (Gear I/II)
 km/h
 5.5/3.5
 Gradeability
 %
 70
 Slew speed
 rpm
 13.3
 Bulldozing plate
 Bulldozing plate (width)
 mm

 Bulldozing plate (height)
 mm

 Lifting distance (GL up/down)
 mm

 Hydraulic pump type
 Piston pump×2
 Fuel tank capacity
 L
 360
 Hydraulic oil tank capacity
 L
 220
