• Model NO.：JG-80L
• Size：Small-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Track Gauge：1570mm
• Applicable Railway Gauge：1000mm~1435mm
• Efficiency：≥40pic,H
• Angle of Rotation：360°
• Machine Weight：8000kgs
• Transport Package：Nude Packing
• Specification：6100*2200*2650mm
• Trademark：JING GONG
• Origin：China
• Production Capacity：3000sets,Year

Range of operation Boom length3320mmArm length1850mmMaximum Digging Force45KNBack-end radius of gyration1750mm(Length*width*height)Transport Dimensions(Length*width*height)Transport Dimensions6100*2200*2650mmWheel base2900mmTrack Gauge1570mmWidth Of Crawler400mmGround clearance of counterweight780mmMin ground clearance280mmTech performance and specificationApplicable railway gauge1435mmefficiency≥40pic/hAngle of rotation360°Machine weight8000kgEngine modelYUCHAI(III)Rated Power48KWRated Speed2200r/minHydraulic system working pressure21MpaHydranlic system flow120L/minVariable piston pump28ml*2/rWalking speed(High speed/low speed)4.5/2.5km/hGrade Climbing ability70%/35°Volume Of Bucket0.25m3Swing Overload Pressure16MpaFull circle swinging time5.5sFqt Fuel Quantity ≥4L/hCapacity Of The Fuel Tank110LHydraulic Tank Capacity 110L
