High Quality Crawler Excavator 920e with 124kw Engine

Sinomada Heavy Industry (Changsha) Co., Ltd.
  • After-sales Service：1 Year
  • Warranty：1 Year
  • Type：Crawler Excavator
  • Usage：GM Excavator
  • Bucket：Backhoe
  • Transmission：Hydraulic Transmission

Base Info

  • Model NO.：920E
  • Drive Type：Internal Combustion Drive
  • Bucket Capacity：0.87,0.95,1.0,1.2 Cbm
  • Size：Small-Scale
  • Certification：CE, ISO9001: 2000
  • Condition：New
  • Operating Weight with Cab：21500 Kg
  • Engine Power：112 Kw,1950 Rpm-124 Kw,2050rpm
  • Maximum Travel Speed (High)：5.3,5.7km,H
  • Maximum Travel Speed (Low)：3.0,3.3 Km,H
  • Maximum Swing Speed：10.5,12.5 Rpm
  • Track Shoe Width (Std)：600 mm
  • Digging Depth：6562 mm
  • Dumping Height：7170 mm
  • System Pressure：34.3MPa
  • System Maximum Flow：2*224 L,Min ( 2*59 Gal,Min)
  • Transport Package：Nude Package,RO-RO,Bulk Shipment,Suitable Containe
  • Specification：9570,9540 mm*2800 mm*3140 mm
  • Origin：China
  • Production Capacity：300piece,Month

Description

Operating weight with cab21500 kgEngine power112 kW (150 hp) @ 1950 rpm-124 kW (166 hp) @ 2050 rpmBucket capacity0.9/0.95/1.0/1.2 m³Maximum travel speed (High)5.3/5.7/4.9 km/hMaximum travel speed (Low)3.0/3.3/2.9 km/hMaximum swing speed10.5/12.5/12 rpmArm breakout force97 kNArm breakout force Power boost105 kNBucket breakout force140 kNBucket breakout force Power boost152.5 kNShipping length9570/9540 mmShipping width2800 mmShipping height3140 mmTrack shoe width (std)600 mmBoom5710 mmArm2915 mmDigging reach9870 mmDigging reach on ground9685 mmDigging depth6562 mmVertical wall digging depth5080 mmCutting height9945 mmDumping height7170 mmMinimum front swing radius3090 mmModelCEmissionEPA Tier 2 / Tier 3 / EU Stage II / Stage IIIASystem maximum flow2×224 L/min ( 2x59 gal/min)System pressure34.3 MPa
