• Model NO.：XS163J
• Compaction Depth：40cm
• Engine Type：Diesel Engine
• Travel Speed：35cm,s
• Centrifugal Force：290,200kn
• Certification：ISO 9001:2000, ISO 9001:2008
• Condition：New
• Transport Package：Nude
• Trademark：Top Brand
• Origin：Jiangsu, China
• HS Code：8429521200

Basic Info.

Model NO. XS163J Compaction Depth 40cm Engine Type Diesel Engine Travel Speed 35cm/s Centrifugal Force 290/200kn Certification ISO 9001:2000, ISO 9001:2008 Condition New Transport Package Nude Trademark Top Brand Origin Jiangsu, China HS Code 8429521200

Product Description

  Road Roller XS163J with Single Drum VibratoryFeature:
Focus industry is a company that have been doing machinary products business for many years .For now we could supply  roader roller from 12 tons to 30 tons , if you cannot find out the model you are looking for , please kindly contact me for help.
XS142J/XS162J/XS182J vibratory compactor is a kind of heavy duty self-propelled vibratory compactor. It can effectively compact various soil layers and rock fill, and can be applied to the constructions of modern freeways, airports, embankment fill, ports, dams, railways, mines, etc.
Performance feature
The spacious and bright cab features wide view and comfort.
Simple operation
The humanity instrument panel has a reasonable layout, all the control buttons are clear at a glance.
Adopt the gearbox with synchronizer, which is easy to operate.
The special compactor drive axle has the function of preventing slipping, featuring strong traction.
Reliable and durable hydraulic system
The standard configuration includes imported open gear pump and motor. The optional configuration includes closed hydraulic vibration system, imported piston pump, motor (16t, 18t). All those have a long service life, supplying stable start-oscillation and oscillation stop and high compacting quality.



Model	Unit	XS162J
Operating weight	kg	16000
Weight on front drum	kg	7700
Static linear pressure	N/cm	362
	km/h
Speed I		2.54
Speed II		4.97
Speed III		10.51
Theoretical gradeability	%	30
Min. external turning radius	Speed range	6500
Steering angle	°	±33
Oscillating angle	°	±11
Vibration frequency	Hz	28
Nominal amplitude (high/low)	mm	1.9/0.95
Excitation force (high/low amplitude)	kN	290/145
Engine model		SC8D156.2G2B1
Type	Water cooled, pressurized	Water cooled, pressurized
Max. power	kW	115@1800r/min
Engine oil consumption	g/kW.h	223
Hydraulic oil tank capacity	L	170
Fuel tank capacity	L	240
