| Manufacturer | XGMA |
| Model | XG932H |
| Overall length(mm) | 6970 |
| Overall height(mm) | 3330 |
| Overall width(mm) | 2245 |
| Wheel base(mm) | 2750 |
| Ground clearance(mm) | 356 |
| Tread(mm) | 1800 |
| Bucket Width (mm) | 2420 |
| Turn radius(mm) | 5280 |
| Min.Turn radius outside of bucket (mm) | 5860 |
| | 3930 |
| Max. Dumping Height(mm) | 3060 |
| Dumping Reach(mm) | 1020 |
| Digging depth(mm) | 100 |
| | 50 |
| | | |
| Engine model | YC6J125Z-T20 |
| Rated power (kw) | 92 |
| Fuel comsumption per hour(g/kw.h ) | 225 |
| Rated speed (r/min) | 2200 |
| Max torque(N.m) | 500 |
| Operating Weight (Tonnes) | 10.8 |
| Rated Load(Tonnes) | 3.2 |
| Bucket capacity (m3) | 1.4-3.0 |
| Lifting time/Lifting, dumping and lowering(s) | 6/10.4 |
| Max Breakout force(KN) | 100 |
| Max.drawing force (KN) | 103 |
| Max. turning angle(°) | ±35° |
| Climbing ability(°) | ≤ 30 ° |
| Fuel tank(L) | 140 |
| Hydraulic tank(L) | 160 |
| Working pressure of steering hydraulic system(MPa) | 13 |
| Working pressure of load hydraulic system(MPa) | 16 |
| Travel speeds(km/h) | FORWARD 1ST | 0~12 |
| FORWARD 2ND | 0~40 |
| FORWARD 3RD | |
| FORWARD 4TH | |
| REVERSE 1ST | 0~16 |
| REVERSE 2ND | |
| Gear Box | XG |
| Axle | XG |
| Implement pump | 132 |
| Distibuting valve | DF25-2C |
| Steering Hydraulic system | BZZ5-500 |
| Steering pump | 90 |
| Tyre size | 17.5-25-12PR |
| Air Conditioning/Anti-mist when idleing | √ |
| Heating | √ |
| Radio/Cassette | √ |
| Bucket and arm raiseing (limit height) Device | × |
| Hydraulic Operation system | √ |
| Seat Buckle | √ |
| Head lamp | √ |
| Reversing Alarm (Back vehicle) | √ |
| ROPS/FOPS | × |
