Mobile Asphalt Distributor Trailer
Wuhan Kudat Industry & Trade Co., Ltd.- Type:Asphalt Distributor
- Object:Asphalt Concrete Pavement
- Moving Type:Semi-Fixed
- Mixing Method:Intermittent Compulsory
- Automatic Grade:Non-Automatic
- Product Capacity:<40t,h
Base Info
- Model NO.:LB1000
- Certification:ISO9001: 2000, CE
- Condition:New
- Dimension:3460X1820X1800mm
- Loading Weight:1000kgs
- Tank Capacity:1000L
- Diesel Engine Model:Sf180 Single Cylinder
- Insulation Layer Thikcness:50mm
- Operation Weight:1180kgs
- Engine Power:5.67kw2660rpm
- Asphalt Pump Displacemen:30L,Min
- Bitumen Temperature:120-160
- Air Compressor:0.08 M3,Min
- Transport Package:by Sea Required
- Specification:ISO
- Trademark:Kudat
- Origin:China
- HS Code:870590999
- Production Capacity:50, 000 PCS,Year
Description
Basic Info.
Model NO. LB1000 Certification ISO9001: 2000, CE Condition New Dimension 3460X1820X1800mm Loading Weight 1000kgs Tank Capacity 1000L Diesel Engine Model Sf180 Single Cylinder Insulation Layer Thikcness 50mm Operation Weight 1180kgs Engine Power 5.67kw2660rpm Asphalt Pump Displacemen 30L/Min Bitumen Temperature 120-160 Air Compressor 0.08 M3/Min Transport Package by Sea Required Specification ISO Trademark Kudat Origin China HS Code 870590999 Production Capacity 50, 000 PCS/YearProduct Description
LSD1000 Trailer Aspshalt Distributor with Diesel burnerLSD1000 Trailer Asphalt Distributor
*Energy-saving, environmental Protection
*Simple reliable
*Opration Convenience
*Fast Transportantion
LSD1000 trailer asphalt distributor is a repairing maintenance equipment; It adapt to country road low grade road, high quality and good price, good stability and using expedience.
This trailer designed with hand spray gun, it's quite easy for operation.
General Description:
The unit including tank mounted on trailer, made up of by asphalt tank, drive system, transmission system, pipeline system, asphalt pump, heating system, hand sprayer system etc. This is units can suitable for hot bitumen and emulsion bitumen transportation and spray, use hot bitumen the temperature need to reach 160~180 degree.
Asphalt tank:
The Max. Tank capacity is 1000 Liters, the tank made by carbon steel inside with 50mm thickness heat preservation material (silicic acid aluminum). Hand brake, inside the tank has heating system, also the tank connecting with hand spray system, and the spray value around 30 L/min.
Heating system:
The vehicle has its own heating system, the burner model is PQ5, the fuel tank capacity is 13.5 Liters, the burner flame could be adjusted by the hand valve.
Drive system:
We adopted diesel engine, the model is R180, power 5.67/2660 (Kw/rpm).
ITEM | PARAMETER |
Model | LSD1000 |
Dimension(mm) | 3460X1820X1800 |
Diesel Engine Model | R180 |
Diesel Engine Power(Kw/r/min) | 5.67/2660 |
Empty weight(Kg) | 1180 |
Loading Weight(Kg) | 1000 |
Tank Capacity(L) | 1000 |
Asphalt Pump Displacement (L/min) | 30 |
Bitumen temperature | 120-160 |
Insulation thicknes(mm) | 50 |
Air compressor | 0.08 m³/min |
