• Model NO.：SWSS4000
• Certification：ISO9001: 2000
• Condition：New
• Spreading Width：250-4000 mm
• Rated Power：213 Kw
• Spreading Speed：2.5-3.6 Km,H
• Brand：Sinoway
• Warranty：One Year
• Model：Swss4000
• Transport Package：Naked
• Specification：ISO9001
• Trademark：SINOWAY
• Origin：CHINA
• HS Code：84314990
• Production Capacity：10 Units,Month

Basic Info.

Model NO. SWSS4000 Certification ISO9001: 2000 Condition New Spreading Width 250-4000 mm Rated Power 213 Kw Spreading Speed 2.5-3.6 Km/H Brand Sinoway Warranty One Year Model Swss4000 Transport Package Naked Specification ISO9001 Trademark SINOWAY Origin CHINA HS Code 84314990 Production Capacity 10 Units/Month

Product Description

Product Description
1-The spreading amount is large, can meet the requirement of a variety of aggregate spreading.

2-Proportional control of the feed roller speed and the spreading speed, uniform spreading of the aggregates.
3-Combined control of belt feeding & the material level device, having achieved automatic control of material feeding.
4-The speed of the screw is synchronized with the speed of the feed roller, which is beneficial to the feeding and to the prevention of segregation.
5-The travelling system adopts the power transmission device of the heavy truck, the cost of maintenance is low.
6-Self locking traction hook, can realize convenient connection & separation between the spreader and the skip car in the continuous spreading.
7-High power diesel engine, its sufficient power reserve can adapt to various conditions of spreading and to resistance to heavy load changes.
8-Using the principle of automobile gas path control, so that braking and clutch operation are light and flexible, safe and reliable.
9-Two independent braking systems are used to ensure safe and reliable driving.
10-The mode of using advanced clutch to coordinate with gas assistance, greatly reduces the control force.

Product Show

Specifications


Engine model	WP10
Type	Six-cylinder water cooled,turbocharged
Rated power	213kw
Rated speed	2200rpm
Spreading width	250~4000mm
Spreading speed	2.5~5km/h
Max.travel speed	23km/h
Max. spreading capacity	22 L/m²
Min. spreading capacity	2 L/m²
Aggregate size	3-40mm
Belt speed	100 r/min
Screw speed	42 r/min
Feed roller speed	42 r/min
Lateral spreading rate	≥95%
Longitudinal spreading rate	≥96%
Front spread hopper volume	1.5m³
Rear hopper volume	2.8m³
Dimension of spread hopper	4240×940×1340mm
Min. turning radius	14000mm
Wheelbase	3850mm
Min.ground clearance	185mm
Max.steering angle (front wheel)	18°
Overall dimension	7660×4240×3660mm
Operating weight	12500kg
