• Model NO.：TS120N
• HS Code：84291190
• Production Capacity：1000 Units

Basic Info.

Model NO. TS120N HS Code 84291190 Production Capacity 1000 Units

Product Description

General Introduction of 120HP Crawler Bulldozer for wet land (TS120N)
1)Engine choose the pressure rising engine produced by British  Ricardo joint-venture technology,low oil consumption and stronger torsion.
2)Turning clutch:choose dry and multi-piece turning clutch,manually operating with hydraulic pressure, easily maintenance ,lightly and convenient operation.
3)Filter applied in desert is more applicable for coal reserve site ,desert and other special work condition.
4)Operation environment is fully closed , hexahedral cab with lower noise ,effiectively reducing noise beside your ear ,extending your visual field and effectively improving comfort.
5)Electric system is characterized by electronic monitor ,making real-time monitor for complete machine to assure normal operation.
6)Operationi device several device such as direct-pouring shovel .environmentally hygienic ,angle shovel .coal-pushed shovel and soil scarifier are available for user.

Specification of 120HP Crawler Bulldozer for wet land (TS120N)

Main Specification	Unit	T120N
Total weight	kg	13500
Max towing force	kN	115
Engine model		LR6A3Z-20
Engine rated power	kw	93
Engine rated speed	r/min	2000
Fuel Consumption of the engine	g/kw.h	≤235
Engine max torque	N.m	526
Traveling speed	km/h
Forward I-IV gears	km/h	2.4~10.6
Reverse I-II gears	km/h	3.8~7.0
Caterpillar track board width	Mm	720
Land pressure	Kpa	37
Overall length	Mm	4610
Overall width	Mm	3450
Overall height	Mm	2900
Blade width	Mm	3450
Blade height	Mm	1060
Blade max lifting height	Mm	894
Blade max digging depth	Mm	400
Cutting angle(adjustable)	°	55
