102HP 1 M3 3 Ton Hydraulic Loader, Mini Hydraulic Loader

Jinan Sinoheng Import and Export Co., Ltd.
  • Certification：TUV, UL, ISO, RoHS, CE, ISO9001: 2000
  • Condition：New
  • Rated Load：2600kg
  • Transmission：Hydraulic
  • Walking Mode：Wheeled
  • Type：Small Loader

Base Info

  • Model NO.：932
  • Bucket Capacity：1.1m3
  • Rated Power：75kw (102HP)
  • Bucket Width：2000mm
  • Operating Weight：5300kg
  • Dumping Height：3500mm
  • Min Turning Radius：5500mm
  • Max. Breakout Force：40kn
  • Tyre：6.70-24
  • Engine Power：74~147kw
  • Transport Package：Container
  • Specification：CE, ISO9001: 2000
  • Trademark：SINOHENG
  • Origin：China Shandong
  • Production Capacity：500PCS,Month

Description

Descriptions & Specifications932DescriptionParameterEngine DetailsModel4108 (YTO)Engine typeIn-linearrangement, water-cooled, four-cycle diesel Engineturbo intercoolerRated Power75KW (102HP)Rated Speed2400 r/min (rpm)Transmission SystemTypehydraulictorque converterBucketBucket Capacity1.1m3Bucket width2000mmMax. Breakout Force40KNRated Load2600kgOperating Weight5300kgOverall DimensionsOverall Length (Bucket on ground position)5950mm
 Overall Height Ground to Cab Top2950mmGround to exhaust pipeIt is below from the top of cabinDumping Height3500mmOverall Width2000mmOperating SpecificationsSteering SystemArticulated Frame with hydraulic power steeringMin Turning Radius5500mmDriving Systemfour wheel drive ,four wheel brake, wheel reductor bridge.With Pilot ControlBrake SystemService BrakeHydraulic disc brake on four wheelsParking BrakeHand operatedTyreModel16.70-24Wheelbase2100mmTrack1360mmShipment: 2units shipped in 1x40HC
