Small Concrete Vibrator 6kgs with Belt, Japanese Type

Ningbo Ace Machinery Co., Ltd.
  • Type：Concrete Vibrator
  • Shotcrete Type：Semi-Dry
  • Machining Process：Assembly
  • Structure：Rotor Type
  • Productivity：75m²,h
  • Feeding Height：1370mm

Base Info

  • Model NO.：ZIN-160
  • Vibrating Amplitude：1.0mm
  • Certification：ISO9001: 2000, CE
  • Condition：New
  • Color：Green
  • Product Name：Small Concrete Vibrator
  • Power：1500W
  • Speed：4000 Rpm
  • Voltage：220V,50Hz
  • Net Weight：6kgs
  • Matched Vibrator Shaft：Zx-45mm
  • Length：4mtr ,5mtr ,6mtr
  • Hot Sell：in European
  • Transport Package：Carton
  • Specification：1600W
  • Trademark：KZW
  • Origin：Ningbo, China
  • HS Code：84306100
  • Production Capacity：2000 PC,Month

Description

ITEMSmall Concrete vibrator  Model ZIN-160Rated input power1600WRated voltage220V /110VRated Frequency50HZ/60HZNo-load speed4000RPMN.W./G..W6 kgs/7.0kgs
Concrete vibrator shaftModel¢(mm)ZX35ZX-38ZX-45ZX-50ZX-60ZX-70Diameter of head¢(mm)353845505070Length of headL (mm)380420420480410450Vibrating Frequency(HZ)183185185200200200Vibrating Ampitude(mm)0.9111.21.151.151.35Dia of flexiable hoseD(mm)303032363636Diaof flexiable shaftD(mm)101010131313Weight (6mtr)(kg)141516202124packing sizeCM75*75*5.5
