(SD16E) Shantui 160HP Bulldozer

Maxizm Construction Machinery (Qingdao) Co., Ltd.
  • Type：Special Type
  • Transmission：Hydraulic Transmission
  • Walking Mode：Crawler
  • Load and Unload Method：Front Discharge
  • Engine Power：74~147kw
  • Certification：ISO9001: 2000

Base Info

  • Model NO.：160HP
  • Condition：New
  • Color：Yellow
  • Product Name：(SD16e) Shantui 160HP Bulldozer
  • Operatiing Weight：(Kg)T17000
  • Rated Horsepower：120,160
  • Minimum Turning Radius (mm)：4466
  • Ground Pressure：58
  • Model：Weichai Wp10g178e355
  • Horsepower：135
  • Length：5140
  • Width：3388
  • Height：3032
  • Working Hydraulic Tank Capacity：110
  • Fuel Tank Capacity：315
  • Blade Capacity：4.5
  • Maximum Digging Depth of Ripper：592
  • Lift Height of Blade：1095
  • Transport Package：Nude Package
  • Specification：160HP bulldozer
  • Trademark：shantui
  • Origin：China
  • HS Code：8429119000
  • Production Capacity：1000pieces,Year

Description

Length × width × height (mm) (excluding ripper)5140×3388×3032Operating weight(t)(excluding ripper)17.34Engine modelWD10G178E25/ SC11CB184G2B1Net power/rated speed (kW/rpm))120/1850Ground pressure(Mpa)0.059Blade typeStraight tilting blade   Angle blade  U bladeBlade capacity(m3)4.5m3 for straight tilting blade   4.3m3 for angle blade   5m3 for U blade
