• Model NO.：XE470D
• Rated Speed：9.0r,Min
• Maximum Digging Height：10812mm
• Unique Selling Point：Long Lifetime
• Applicable Industries：Construction Works
• Maximum Digging Depth：7881mm
• Max Digging Radius：12066mm
• Hydraulic Valve Brand：Kawasaki
• Hydraulic Pump Brand：Kawasaki
• Operating Weight：47 Tons
• Moving Type：Crawler Excavator
• Engine Brand：Cummins
• Trademark：XCMG
• Origin：Jiangsu, China
• Production Capacity：10000 Unit,Units Per Year

Model

Unit

XE470D

Operating Weight

kg

46900

Bucket Capacity

m

2.2-2.5

Engine

Model

---

QSM11-C335

Type

 Direct injection

---

4 Four strokes

---

 Water cooling

---

 Turbo-charging

---

 Air cooled

---

 No. of cylinders

6

Rated power/swing speed

274/1800

/Torque/swing speed

1790/1400

 Displacement

11

Main performance

Travel speedH/L)

km/h

5.4/3.2

Gradeability

%

70

 Rotary speed

r/min

9.0

Ground pressure

kPa

83

Bucket digging force

kN

287

 Arm digging force

kN

221

Travel traction force

kN

338

Hydraulic

System

Main pump

--

K5V200DTH

Rated flow

L/min

2360

Main safety valve pressure

MPa

31.4/34.3

Pressure of pilot system

MPa

3.9

Oil Capacity

Fuel tank capacity

L

725

Hydraulic tank capacity

L

430

Engine oil capacity

L

38

Appearance

size

A  Total length

mm

12090

B  Total width

mm

3582

C Total height

mm

3860

D Width of platform

mm

2995

E Length of crawler

mm

5353

F Total width of chassis

mm

3582

G Width of crawler

mm

600

H Wheel base of crawler

mm

4292

I Track gauge

mm

2750

J Ground clearance of counterweight

mm

1324

K  Min. ground clearance

mm

519

L Min. rear-end swing radius

mm

3800

Working scope

A Max. digging height

mm

10812

B Max. dumping height

mm

7533

C Max. digging depth

mm

7881

D 8 Max. digging depth at the range of level 8 feet

mm

7700

E Max. vertical digging depth

mm

6870

FMax. digging radius

mm

12066

G Min. swing radius

mm

4802

Bucket capacity

m

2.3 Rock bucket   2.5 Reinforced bucket

Advantage

1,The overall layout and the axle load distribution are more reasonable to achieve better traveling stability and the maximum traveling speed is up to 40km/h to realize faster site transfer speed.

2,The domestic leading hydraulic system distribution technology features high energy-saving and efficiency.

3,The highest breakout force on the loading end is leading the industry by 15%~20% compared with like models.

4,The advanced structure and hinge points on the digging end and the industry's largest rotating angle of the bucket ensure strong soil holding capacity.
