Wheeled Lattice Boom Material Handlers Port Crane with Factory Price
Sinoway Industrial (Shanghai) Co., Ltd.- Type：Wheel Excavator
- Usage：Special Excavator, Marine Excavator, GM Excavator
- Bucket：Grab Shovel
- Transmission：Hydraulic Transmission
- Drive Type：Internal Combustion Drive
- Bucket Capacity：1.0~1.5m³
Base Info
- Model NO.：swmh2500l
- Size：Medium-Sized
- Certification：ISO9001: 2000, ISO14001
- Condition：New
- Working Radius：10.2 M
- Max. Lifting Height：11.3 M
- Engine Power：260HP
- Operating Weight：25ton
- Warranty：One Year
- Transport Package：Nude
- Specification：ISO
- Trademark：SINOWAY
- Origin：China
- HS Code：84314990
- Production Capacity：200 PCS Per Year
Description
Basic Info.
Model NO. swmh2500l Size Medium-Sized Certification ISO9001: 2000, ISO14001 Condition New Working Radius 10.2 M Max. Lifting Height 11.3 M Engine Power 260HP Operating Weight 25ton Warranty One Year Transport Package Nude Specification ISO Trademark SINOWAY Origin China HS Code 84314990 Production Capacity 200 PCS Per YearProduct Description
Product Description1-Dual engine ( Electric motor + Diesel engine) more environmental protection;
2-Electric operation has over-current and heat leakage protection device;
3-Utomatic identification of phase sequence to prevent reverse rotation of oil pump;
4-Hydraulic system power-off, oil self-locking protection device;
5-Multiple compound movements during operation to improve efficiency;
6-The hydraulic system is equipped with air-cooled radiator;
7-The gripper can rotate and change direction automatically 360 degrees;
8-When electric operation is carried out in the upper control room, there is a dual-purpose air conditioner for heating and cooling;
9- Hydraulic Cabin elevatied.
Product Show
Specifications
| Dimensions | |
| Overall length | 7604mm |
| Overall height | 4021mm |
| Overall width | 3435mm |
| Wheelbase | 3600mm |
| The maximum lifting height of driving cab | 5721mm |
| Tail slewing radius | 4175mm |
| Gap between rotary table and ground | 1782mm |
| Width of platform | 627mm |
| Power | |
| Engine | 162kw |
| Electric Motor | 110kw |
| Fuel tank | 295L |
| Walking System | |
| Walking speed | 15km/h |
| Max.tranction force | 110KN |
| Gradeability | 10% |
| Hydraulic System | |
| Max.flow | 2*214L/min |
| Max.working pressure | 28Mpa |
| Hydraulic oil tank | 420L |
| Pilot pressure | 3.6Mpa |
| Main Performance Parameters | |
| Total weight | 40t |
| Max.Lifting moment | 126t.m |
| Max.swing speed | 3.7r/min |
| Max.swing torque | 51KN.m |
