Construction Equipment Se210W Mini Crawler Excavator Price
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：Any
- Warranty：1 Year Warranty
- Type：Crawler Excavator
- Usage：GM Excavator
- Bucket：Shovel
- Transmission：Hydraulic Transmission
Base Info
- Model NO.：SE210W
- Drive Type：Electric Drive
- Bucket Capacity：0.1~0.5m³
- Size：Medium-Sized
- Certification：CE
- Condition：New
- Power：116kw
- Operating Weight：20500kg
- Transport Package：Nude Package
- Trademark：zoomlion
- Origin：China
- HS Code：8429510000
- Production Capacity：20untis,Month
Description
Basic Info.
Model NO. SE210W Drive Type Electric Drive Bucket Capacity 0.1~0.5m³ Size Medium-Sized Certification CE Condition New Power 116kw Operating Weight 20500kg Transport Package Nude Package Trademark zoomlion Origin China HS Code 8429510000 Production Capacity 20untis/MonthProduct Description
Construction Equipment SE210W Mini Crawler Excavator Price
Breaking hammer, ripper, timber grab, stone grab, qu
Paramenters
| Comparative item | SE210W (Standard version) |
| Overall dimensions | |
| Overall length (mm) | 9543 |
| Ground length (During transport) (mm) | 4860 |
| Overall height (To the top of boom) (mm) | 3039 |
| Overall width (mm) | 2800 |
| Overall height (To top of cab) (mm) | 2977 |
| Ground clearance of counterweight (mm) | 1120 |
| Minimum ground clearance (mm) | 470 |
| Tail turning radius (mm) | 2905 |
| Track length (mm) | 4160 |
| Track gauge (mm) | 2200 |
| Track width (mm) | 2800 |
| Standard track shoe width (mm) | 600 |
| Turntable width (mm) | 2726 |
| Distance from slewing center to tail (mm) | 2853 |
| Working range | |
| Maximum digging height (mm) | 10029 |
| Maximum dumping height (mm) | 7320 |
| Maximum digging depth (mm) | 6541 |
| Maximum vertical digging depth (mm) | 5735 |
| Maximum digging distance (mm) | 9860 |
| Maximum digging distance at ground level (mm) | 9673 |
| Working device minimum turning radius (mm) | 3041 |
| Maximum lifting height of bulldozer blade (mm) | - |
| Maximum digging depth of bulldozer blade (mm) | - |
| Engine | |
| Model | Weichai WP7(China III) |
| Type | 6-cylinder, high pressure common rail, and water-cooled and turbocharged |
| Displacement (L) | 7.14 |
| Rated power (kW/rpm) | 116/2000 |
| Hydraulic system | |
| Type of hydraulic pump | Variable displacement duplex plunger pump |
| Rated working flow (L/min) | 2x218 |
| Bucket | |
| Bucket capacity (m³) | 0.9 |
| Swing system | |
| Maximum swing speed (r/min) | 11.5 |
| Brake type | Mechanically applied and pressure released |
| Digging force | |
| Bucket arm digging force (KN) | 92.5/99.5 |
| Bucket digging force (KN) | 115/124 |
| Operating weight and ground pressure | |
| Operating weight (kg) | 20500 |
| Ground pressure (kPa) | 45 |
| Traveling system | |
| Traveling motor | Axial variable displacement plunger motor |
| Traveling speed (km/h) | 3.3/5.4 |
| Traction force (KN) | 201 |
| Gradeability | 70%(35°) |
| Tank capacity | |
| Fuel tank capacity (L) | 360 |
| Cooling system (L) | 25 |
| Engine oil capacity (L) | 24 |
| Hydraulic oil tank/system capacity (L) | 250/420 |
Product pictures
