• Model NO.：LW500FN
• Walking Mode：Wheeled
• Type：Medium-sized Loader
• Rated Operating Loade：5000kg
• Bucket Capacity：3m3
• Machine Weight：16900kg
• Dumping Height：3150~3560mm
• Dumping Distance：1100~1190mm
• Max.Breakout Force：170kn
• Max.Tractive Force：165kn
• Engine Model：162,2000 Kw,R,Min
• Articulated Angle：35º
• Transport Package：Comply with Export Packaging Requirements
• Specification：7910*3016*3515mm
• Trademark：XCMG
• Origin：Xuzhou, Jiangsu, China
• Production Capacity：10000 Unit,Units Per Year

Overview Product Parameters



Item SpecificationUnitRated operating load5000kgBucket capacity2.5~4.5m³Machine weight16900kgDump clearance at maximum lift3150~3560mmReach at maximum lift1100~1190mmWheel base2960mmTread2250mmHeight of hinge at maximum lift height4112mmWorking height(fully lifted)5510mmMax.breakout force170kNHydraulic cycle time-raise6sTotal hydraulic cycle time10.5sMin. turning radius over tyres5950mmArticulation angle35°Gradeability28°Tyre size23.5-25-16PR Overall machine dimension L×W×H7910×3016×3515 ModelWP10G220E21 Rated Power162KwFuel Tank250LHydraulic Tank210LTravel speedI-gear(F/R)13/18km/hII-gear(F/R)40km/h Detailed Photos Our Advantages
