• Model NO.：SWL2820
• Hydraulic Cylinder Brand：Kyb
• Power：41.7,2600kw,Rpm
• Warranty：2 Years
• Dimension(Long * Breadth * High)：3318X1600X2014
• Color：Blue
• Applicable Industries：Manufacturing Plant, Construction Works
• Unique Selling Point：High Power Engine
• Bucket Capacity：0.4mm
• Local Service Location：Indonesia
• Hydraulic Valve Brand：Kyb
• Hydraulic Pump Brand：Kyb
• Machine Weight：1600mm
• Moving Type：Wheel Loader
• Engine Brand：Isuzu
• Showroom Location：Indonesia
• Specification：3318X1600X2014
• Trademark：SUNWARD
• Origin：Hunan, China

Product DescriptionModelSWL2820Dimension(L×B×H)mm3318×1600×2014Working parametersAMaximum overall heightmm3850BHeight to hinge pinmm3002CHeight to top of cabmm2014DHeight to bottom of level bucketmm2834ELength without standard bucketmm2604FLength with sandard bucketmm3318GMaximum dump angle°42HDump heightmm2320JDump reachmm475KRolback angle (bucket on ground)°30LRolback angle at maximum height°97MWheelbasemm987PGroundmm220QDeparture angle°25RTurning radius from center (Coupler)mm1235STurning radius from center (Bucket)mm1953TTurning radius from center (Machine rear)mm1531UBumper overhang behind rear axlemm1021VWidth over tiremm1293WBucket widthmm1600Operating weightkg2830PerformanceRated operating capacitykg750Tipping loadkg1500Breakout force curlkg2000Breakout force liftkg1900Travel speedkm/h13Bucket capacitym30.4EngineBrand KUBOTAModel V2403M-TType 4-cylinder, water cooling, diesel engineEmission standard EPA Tier4 / EU Stage III APowerkW/rpm41.7/2600Maximum torqueN.m/rpm163.6/1800Electrical SystemStarting motorV/kW12/2.0GeneratorV/A12/60BatteryAh120Fueling AmountHydraulic oil tankL35Fuel tankL75Hydraulic SystemStandard dischargeL/min67Large dischargeL/min98Standard working pressurebar210Large-discharge working pressurebar165
