• Model NO.：933E
• Size：Small-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Operating Weight with Cab：31800-32900 Kg
• Engine Power：160 Kw (215 HP) @ 2200 Rpm
• Arm Breakout Force：137 Kn
• Bucket Breakout Force：187kn
• Trademark：Liugong
• Origin：China

Basic Info.

Model NO. 933E Size Small-Scale Certification CE, ISO9001: 2000 Condition New Operating Weight with Cab 31800-32900 Kg Engine Power 160 Kw (215 HP) @ 2200 Rpm Arm Breakout Force 137 Kn Bucket Breakout Force 187kn Trademark Liugong Origin China

Product Description

Top Brand Durable 33Ton Crawler Excavator 933E Best Price

• Heavy duty rollers, reinforced idler frame and optional full track guard guarantee the integrity of our undercarriage. It's this core strength that enables our customers to keep working and earning - around the clock.
• ROPS (Roll Over Protection System) and FOPS (Falling Object Protection System) safeguard your most important asset: your operator in the toughest environment.
• Visibility is key to protecting your operator and workers on site. The large glass surface area, increased by 15% on the E-series cab compared with our previous model, combined with the rear-view camera, provides an extraordinary view of the 933E's surroundings.
• Greater hydraulic flow and higher swing speeds combine to improve cycle times by 12% on tasks such as truck loading, digging, trenching and backfilling compared with our previous model.

Operating weight with cab  31800-32900 kg

Engine power  160 kW (215 hp) @ 2200 rpm

Bucket capacity  1.4 / 1.6 m³

Maximum travel speed (High)  5.5 km/h

Maximum travel speed (Low)  3.0 km/h

Maximum swing speed  10.3 rpm

Arm breakout force  137 kN

Arm breakout force Power boost  149 kN

Bucket breakout force  187 kN

Bucket breakout force Power boost  203 kN

Shipping lengt 10650 mm

Shipping width  3190 mm

Shipping height  3525 mm

Track shoe width (std)  600 mm

Boom  6200 mm

Arm  3050 mm

Digging reach  10653 mm

Digging reach on ground  10453 mm

Digging depth  7300 mm

Vertical wall digging depth  6216 mm

Cutting height  10300 mm

Dumping height  7265 mm

Minimum front swing radius  4040 mm

Model  Cummins 6C8.3

Emission  EPA Tier 2 / EU Stage II

System maximum flow  2×266 L/min (2x70 gal/min)

System pressure  34.3 MPa
