• Model NO.：SG21-3
• HS Code：8426990000
• Production Capacity：5000 Units Per Year

ITEM
SG21-3
Engine
Cummins 6CTAA8.3-C215
Scarifier
No
Rated power (kW/rpm)
160/2200
Travel speed (km/h)
Forward 1
0-5.4
Forward 2
0-9.4
Forward 3
0-12.2
Forward 4
0-20.5
Forward 5
0-25.4
Forward 6
0-39.7
Reverse 1
0-5.4
Reverse 2
0-12.2
Reverse 3
0-25.4
Dimensions (L×W×H) (mm)
9260×2600×3400
Minimum turning radius (mm)
8200
Wheel base (mm)
2155
Gradeability (°)
20
Maximum traction (KN)
90
Maximum cutting depth (mm)
500
Operating weight (kg)
17000
Blade width (mm)
3660/3965/4270
Blade height (mm)
635
Blade rotational angle (°)
360
Maximum lifting height (mm)
410
Blade cutting angle adjustment Range (°)
44-91
Min. ground clearance (mm)
430
Working hydraulic system pressure (MPa)
16
Brake System Pressure (MPa)
10
