• Model NO.：SEM653D
• Load and Unload Mode：Front Discharge
• Walking Mode：Wheeled
• Type：Medium-sized Loader
• Model：Sem653D
• Bucket Capacity：3.0m 3
• Max. Drawbar Force：178kn
• Breakout Force：168kn
• Max.Breakout Force：,
• Dump Clearance：2691mm
• Wheel Base：3300mm
• Rated Speed：2200r,Min
• Operating Weight：18t
• Dumping Reach：1845mm
• Transport Package：Null
• Specification：8279*2963*3456mm
• Trademark：MAXIZM
• Origin：Shandong, China
• HS Code：8429510000
• Production Capacity：1000, Month

Overview Product DescriptionProduct ParametersSPECIFICATIONS FOR SEM656 D WHEEL LOADERRated Load(kg)5000Operating Weight(kg)16800Bucket Capacity(m³)2.7-4.5Wheelbase(mm)3300Overall Dimensions (mm)(L*W*H)8279*2963*3456Turning Radius(mm)6813Max. Breakout Force(KN)178Max. Tractive  Force(KN)168

TransmissionmodelTR200Transmission typefixed shaft power shift transmissiongear shiftF4/R4torque converter typeunipolar three element centripetal
Drive axleMain  drive typesingle screw speed reducerwheel reduction typeprimary planetary reducerswing angle(°)±11

Diesel enginemodelWP10G220E343rated power(KW)162rated speed(r/min)2000displacement(L)9.7

Hydraulic systemtypeQuantitative/variable double pump converging/diverter hydraulic systemboom lift time(s)5.1Hydraulic cycle time (Total)(s)9.3working pressure(MPa)18
brake system Service BrakeAir assisted oil disc type four wheel brakeParking Brake internal expansion

tireModel23.5-25typelow pressure wide base diagonal tirelayer16pattern typeL3Detailed Photos
