2021 Big Discount Mini Excavator 2ton with Briggs & Stratton Engine for Sale
Shandong TOROS Machinery Co., Ltd.- After-sales Service：Provide a Lifelong Online Problem Solution
- Warranty：12 Months Warranty Service
- Type：Crawler Excavator
- Usage：Mining Excavator, GM Excavator
- Bucket：Backhoe
- Transmission：Hydraulic Transmission
Base Info
- Model NO.：TE20
- Drive Type：Internal Combustion Drive
- Bucket Capacity：0.06cbm
- Size：Small-Scale
- Certification：CE, ISO9001: 2000, Euro 5 & EPA Approved
- Condition：New
- Excavator Width：1060mm
- Track Length：1900mm
- Track Width：230mm
- Volume of Fuel Tank：26L
- Transport Length：3600mm
- Excavator Height：2200mm
- Turning Radius：1150mm
- Max.Digging Height：3400mm
- Max.Digging Depth：2100mm
- Max.Digging Radius：3300mm
- Max.Vertical Digging Depth：2000mm
- Max.Digging Force：14kn
- Engine：Laidong , Yanmar
- Engine Power：18.1kw,2200rpm 19.6kw,2300
- Weight：1900kg
- Transport Package：FCL and LCL
- Specification：3600*1060*2200mm
- Trademark：TOROS
- Origin：Shandong, China
- HS Code：8429521200
- Production Capacity：5000sets,Month
Description
TE20 Mini Crawler excavator METRIC IMPERIAL Bucket Capacity 0.06m³ Bucket Capacity 2.12ft³ Excavator Width 1060mm Excavator Width 41.73in Track Length 1900mm Track Length 74.8in Chassis Ground Clearance 230mm Chassis Ground Clearance 9.06in Track Width 230mm Track Width 9.06in Volume of fuel tank 26L Volume of fuel tank 5.72UK gal Gradeability 30° Gradeability 86ºF Transport Length 3600mm Transport Length 141.73in Excavator Height 2200mm Excavator Height 86.61in Overall Dimension ( LxWxH) 3600*1060*2200mm Overall Dimension ( LxWxH) 141.73*41.73*86.61in Multi-way Valve Traveling Motor Multi-way Valve Traveling Motor Engine LAIDONG / YANMAR Engine LAIDONG / YANMAR Engine Power 18.1kw/2200rpm 19.6KW/2300 Engine Power 24.27hp/2200rpm 26.28hp/2300rpm Turning Radius 1150mm Turning Radius 45.28in Max.Digging Height 3400mm Max.Digging Height 133.86in Max.Dumping Height 2200mm Max.Dumping Height 86.61in Max.Digging Depth 2100mm Max.Digging Depth 82.68in Max.Digging Radius 3300mm Max.Digging Radius 129.92in Max.Vertical Digging Depth 2000mm Max.Vertical Digging Depth 78.74in MAX.Digging Force 14KN MAX.Digging Force 14KN Weight 1900kg Weight 4188lb 12.5oz EATON Swing Motor Tianji Hydraulic Pump EATON Swing Motor Tianji Hydraulic Pump
Excavator & features
-----------------------------------
1. Excavators with compact dimensions can easily drive through narrow passages and doors.
2. Retractable undercarriage and dozer blade allow the excavators to be configured for excellent working stability and optimum performance.
3. Powerful engine and perfectly matched hydraulics provide efficient, economical and reliable performance for the toughest of jobs.
4. Bucket hoses are well protected within the boom and the cylinder is mounted above the structure.
5. The operator area is spacious and laid out to provide comfort and ease of operation.
6. Excellent engine provides excellent power with minimal fuel use for more productivity per tank.
