• Model NO.：W156
• Load and Unload Mode：Front Discharge
• Walking Mode：Wheeled, Wheeled
• Type：Medium-sized Loader, Universal Type
• Load and Unload Method：Front Discharge
• Engine Power：147~515kw
• Color：Yellow
• Wheel Loader Bucket Capacity：3m3
• Wheel Loader Weight：16200kg
• Wheel Loader Engine Power：220HP
• Wheel Loader Dumping Height：3100mm
• Wheel Loader Tyre Size：23.5-25
• Wheel Loader Hydraulic Pressure：17MPa
• Max. Travelling Speed：37.5km,H
• Wheelbase：3427mm
• Total Hydraulic Cycle Time：11.1s
• Transport Package：One Unit Per 40hq Container
• Specification：ISO9000 CE Gost-R
• Trademark：WORLD
• Origin：China
• HS Code：84295100
• Production Capacity：5000PCS,Year

Main Standard ConfigurationBucket Capacity3.0 CBMRated Load5000kgTravelling Speed Forward 1st0-11.5km/hForward 2nd0-37.5km/hReverse 1st:0-17km/hMax. Traction165kNMax. Break Out Force150kNMin. Turning Radius (outside tires)6700mmMax. Dumping Height3100mmMax. Reach1200mmTotal Hydraulic Cycle Time≤ 11.1sFull Bucket Lifting Time5.7sDimensions (LxWxH)8075x2960x3500mmMin. Clearance Over Ground380mmOperating Weight16200kg  Diesel Engine ModelDongfeng CUMMINS 6CTA8.3 or Shangchai C6121 or Weichai SteyrTypeDirect injection, turbocharged, water cooling, 4 strokes, 6 cylindersRated Output160kW/162kW/162kWRated Speed2200rpmMax. Torque855/860/908N. m  Transmission    ModelZL50ManufacturerHangzhou Advance Gearbox Group Co., LtdRated Input Power154kWRated Input Speed2200rpmHydraulic Torque Converter ModelSingle stage, two phase four componentsTorque Ratio When Zero Speed4Transmission Typetwo forward and one reverse gears/power shift, planet type  Mechanical Gear Ratios Gear I2.4346Gear II0.6532Reverse1.7814  I. O. Gear Ratio Of P. T. O. P. T. O. 11.00P. T. O. 21.167Hydraulic Oil Pressure:1.10-1.40MPaInlet Oil Pressure Of Torque Convertor 0.30-0.45MPaOutlet Oil Pressure Of Torque Convertor0.20-0.30MPaLubricating Oil Pressure0.10-0.20MPaMax. Permissible Temp & Outlet Of Torque Convertor120 degree  Transaxle & Tire  Transaxle Typeself-made by Meritor technologyDrive System4 wheel drive Drive RatioBitmap
22.85Rear Axle OscillationCenter oscillationOscillating Angle Of Rear Axle                                                   13°Carrier Assembly Reduction Ratio4.625Wheel End Reduction Assembly Reduction Ratio4.94Tire23.5-25Pressure Of Tire0.28-0.32MPa  Working Hydraulic System Working Pump TypeGear PumpSystem Working Pressure17 MPaWorking Pump Max. Flow Rate  328 l/minLifting Cylinder Bore x Stroke165x757mmTilting Cylinder Bore x Stroke200x540mm  Steering System  TypeArticulation, full hydraulic power steering system with flow-amplified systemSteering Pump Type    gear pump (Model: CBGj2080)Max. Flow Rate43L (1920r/min)Max. Working Pressure12MPaSteering Cylinder Bore x Stroke100x342mmMax. Steering Angle35°  Brake System  TypeAir over hydraulic disc on four wheels brakesDrive Brake System Pressure0.71-0.784MPaParking Brakeinner expanding shoe brake, air cylinder and spring energy reverse, applied via a switch on the control stand panel  Oil Injection Capacity Fuel Tank300LEngine Oil30LTransmission45LHydraulic Oil Tank200LTransaxle30L
