High Quality Highway Guardrail Installing Fluid-Drive Pile Driver
Ji Ning Hengwang Mining Machinery Co., Ltd.- After-sales Service：Yes
- Type：Vibration Piling Machine
- Pressure Pile Driver Type：Hydraulic Pile Driver
- Pile Hammer Type：Hydraulic Hammer
- Power Source：Diesel
- Motor Power：55kw
Base Info
- Model NO.：HW920
- Noise：With Noise
- Condition：New
- Name：Pile Driver
- Loader Type：920
- Power Head Type：75
- Power(Kw)：40
- Impactor Type：110,150low Air Pressure
- Drilling Diameter (Cm)：110-200
- Drilling Depth(M)：1.4-2.6
- Worktable Stroke：40-70cm
- Size(M)：5*2.2*2.74
- Weight：4t
- Transport Package：Nude Package in Container
- Trademark：Hengwang
- Origin：China Shandong
- Production Capacity：500 Sets Per Month
Description
HWH930L Main technical parameters
Working dimension(mm)
5910*2660*4450
Engine power(kw)
55
Transport dimension(mm)
5910*2400*2685
Drive way
four-wheel drive
Chassis body width(mm)
1850
Rotating motor torque(Nm)
1600
Vehicle weight(kg)
5060(10-8)
Mast stroke(mm)
2000
Loader model
ZL930L
Drilling depth(mm)
1650
Hydraulic hammer model
AR68/AR75/AR85
Drilling diameter(mm)
0-300
Work flow(Lmin)
40-70/50-90/60-100
Rail frame inclination0
left35right10
Impact frequency(bmp)
500-900/400-800/400-800
Adjust the angle0
±10
Work stroke(mm)
700-3130
Hydraulic system pressure(Mpa)
16-20
Drill rod diameter(mm)
68/75/85
Gear pump flow(mL/min)
40-50
Hammer force(T)
4-7/6-8/7-14
Sliding stroke left and right(mm)
0-450
Piling efficiency(mm/min)
1500/2000/2500
Height from ground(mm)
720-3100
Walking speed(km/h)
0~26
Air compressor displacement(m3)
5.6/10
Braking method
Air cap oil four-wheel disc brake
Air compressor pressure(MPa)
0.7/0.8
Engine model
YN25GBZ
Gradeability0
24
