Solar PV Power Plant Pile Foundation Pile Driver Ramming Machine

Xuzhou Hengxing Jinqiao Machinery Technology Co., Ltd.
  • After-sales Service：Available
  • Warranty：12 Months
  • Type：Hydraulic Hammer
  • Pressure Pile Driver Type：Hydraulic Pile Driver
  • Pile Hammer Type：Hydraulic Hammer
  • Power Source：Diesel

Base Info

  • Model NO.：HXR5
  • Motor Power：70kw
  • Noise：With Noise
  • Certification：CE, ISO 9001:2008
  • Condition：New
  • Color：Customized
  • Impact Power：1300j
  • Post Diameter：210mm
  • Post Length：6m
  • Engine Brand：FAW
  • Transport Package：Main Machine Nude
  • Trademark：HXING
  • Origin：China
  • HS Code：843010000
  • Production Capacity：1000

Description

HXR5 TECHNICAL PARAMETERSNOItemValueUnit1Dimension(L*W*H)2600*2250(working2650)*2550mm2Weight 2600kg3Hydraulic hammer modelYC260/YC360 4Hydraulic hammer working flow rate50-90/50-90l/min5Impact frequency400-800/400-800bpm6Rod diameter75/85mm7Hydraulic hammer impact powder6-8/7-14T8piling efficency2000/2500mm/min9Engine powder39KW10Walking motor torque(max)1950Nm11Impact drill rotary motor torque800-1800Nm12Mast route2000mm13Drilling depth1700mm14Drilling diameter0-300mm15Max inclination angle of sliding rail rack(left/right)left30/ right10°16Angular adjustment of frame(forwards/backwards)fowards10/ backwards8°17Hydraulic system pressure16-20Mpa18Travelling speed10-15km/h19Pulling speed<=30m/h20Sliding route(left/right)0-450mm21Grade ability<30°22Hydraulic oil tank80L23Diesel oil tank40L24ModelHX26D-1,-2,-3,-4,-5   HX36D-1,-2,-3,-4,-5
