Construction Gjj Passenger Hoist Parts Rubber Coupling
SYM Hoist & Tower Crane Equipment Co., Ltd.- Type：Rubber
- Application：Tower Crane
- Certification：CE, ISO9001: 2000
- Condition：New
- Warranty：3 Months
- Transport Package：Carton
Base Info
- Model NO.：All Models
- Specification：1 set
- Trademark：SYM
- Origin：China
- HS Code：8431499900
- Production Capacity：5000,Month
Description
Basic Info.
Model NO. All Models Specification 1 set Trademark SYM Origin China HS Code 8431499900 Production Capacity 5000/MonthProduct Description
Our main products are construction hoist &elevator spare parts rubber coupling and spare parts like the motor reducer ,mast section,safety device , ....
France,type and QTZ type tower crane parts, mast section. anchore frame, fixing angle, pin, bolt, various mech, assembly and spare parts, control box, resistance box and spare parts, drive room and spare parts, wire rope, pulley, cable etc. complete anti-parts
We can also supply any part of tower crane,such as hoisting mechanism,trolleynig mechanism,slewing mechanism and so on.
| 14kg coupling | 17 kg coupling | 22 kg coupling | |
| bearing width (H) | 121-123.5 | 121-123.5 | 121-123.5 |
| Large half thickness (H1) | 84 | 84 | 84 |
| Small half thickness (H2) | 74 | 74 | 74 |
| Elastomer thickness (h) | 35 | 35 | 35 |
| Outer diameter (D) | Φ205 | Φ210 | Φ210 |
| Step diameter (D1) | Φ100 | Φ120 | Φ120 |
| Large half hole length (L1) | 80 | 80 | 78 |
| Large half aperture (d1) | Φ38 | Φ38 | Φ38 |
| Horizontal key width (B1) | 10 | 10 | 10 |
| Spline length (L2) | ≥35 | 41 | 42 |
| Spline minor diameter (d2) | Φ35 | Φ35 | Φ35 |
| Spline major diameter (d3) | Φ40 | Φ40 | Φ40 |
| Spline key width (B2) | 10 | 10 | 10 |
| Speed (n rpm) | 1500 | 1500 | 1500 |
| Rotating inertia (l Kg.m2) | 0.065 | 0.093 | 0.105 |
