• Model NO.：HW400R
• Motor Power：90kw
• Noise：With Noise
• Condition：New
• Product Number：Pile Driver
• Hydraulic Hammer Model (mm)：75,85,100
• Hydraulic Hammer Flow (L/Min)：50-110
• Impact Frequency (BMP)：350-800
• Walking Motor Torque (N.M)：<11500
• Drill Rod Diameter (mm)：75,85,100
• Frame Rotation Angle (°)：360
• Hydraulic System Pressure (MPa)：22
• Traveling Speed (Km/H)：3
• Vehicle Weight (Kg)：6200
• Engine Power (Kw)：85
• Engine Rated Speed (R/Min)：2600
• Track Shoe Width (mm)：350
• Transport Package：Standard Export Package
• Specification：180cm*96cm*110cm
• Trademark：HW
• Origin：China
• HS Code：84305090
• Production Capacity：1000 Set,Sets Per Month

Product number

HWL400R

Hydraulic hammer model (mm)

75/85/100 optional

Hydraulic hammer flow (L/min)

50-110

Impact frequency (bmp)

350-800

Drill rod diameter (mm)

75/85/100

Walking motor torque (N.m)

<11500

Pile height (mm)

According to the slide

Sliding guide frame inclination angle (°)

(Left) 5(Right) 5

Frame rotation angle (°)

360

Hydraulic system pressure (mpa)

22

Gear pump displacement (ml/r)

40+40+25

Traveling speed (km/h)

3

Vehicle weight (kg)

6200

Engine power (kw)

85

Engine rated speed (r/min)

2600

Track shoe width (mm)

350

Track single (section)

42

Total displacement of walking motor (ml/r)

53

Rated pressure of walking motor (mpa)

30

Travel motor reduction ratio

1:54.4

Dimensions (mm)
