• Model NO.：GR180
• Engine Model：6ctaa8.3 D6114
• Rated Power/Speed：138kw,2200 140kw,2300rpm
• Operating Weight(Standard)：15400kg
• Travelling Speed ,Forward：5,8,11,19,23,38 Km,H
• Travelling Speed ,Reverse：5,11,23 Km,H
• Tractive Force(F=0.75)：79kn
• Max. Gradeability：20%
• Tire Inflation Pressure：260 Kpa
• Working Hydraulic Pressure：16 MPa
• Transport Package：Nude Package
• Specification：8900*2625*3470mm
• Trademark：maxizm
• Origin：Jiangsu, China
• HS Code：8429209000
• Production Capacity：1000units,Year

Basic specification

Engine model6CTAA8.3 D6114Rated power/speed138kW/2200  140kW/2300rpmDimension(LxWxH)8900×2625×3470mmOperating weight(Standard)15400kg

Performance specification

Travelling speed ,forward5,8,11,19,23,38 km/hTravelling speed ,reverse5,11,23 km/hTractive force(f=0.75)79KNMax. gradeability20%Tire inflation pressure260 kPaWorking hydraulic pressure16 MPaTransmission pressure1.3~1.8MPa

Operating specification

Max. steering angle of front wheels±50°Max. lean angle of front wheels±17°Max. oscillation angle of front axle±15°Max. oscillation angle of balance box15Frame articulation angle±27°Min. turning radius using articulation7.3mBiadeMaximum lift above ground450mmMaximum depth of cutting500mmMaximum blade position angle90°Blade cutting angle28°-70°Circle reversing rotation360°Moldboard width X height3965×610mm
