8ton Crawler Excavator with CE Approved CT80-7b

Wuhan Kudat Industry & Trade Co., Ltd.
  • Type：Crawler Excavator
  • Usage：GM Excavator
  • Bucket：Shovel
  • Transmission：Mechanical Transmission
  • Drive Type：Internal Combustion Drive
  • Bucket Capacity：0.1~0.5m³

Base Info

  • Model NO.：CT80-7B
  • Size：Small-Scale
  • Certification：CE
  • Condition：New
  • Color：Yellow
  • Function：Earthmoving
  • Transport Package：Bulk
  • Specification：SGS CE
  • Trademark：KUDAT
  • Origin：China
  • Production Capacity：500PCS,Year

Description

ENGINE  Model  Yanmar 4TNV94L  Type  Natural aspirated  Number of cylinder  4  Max. power/rpm  37.9kw/2200rpm  Max. torque  217N.M at 1000 rpm  Displacement  3.054L  HYDRAULIC SYSTEM  Main pumps   Type  Variable displacement axial piston pumps  Max. displacement  63cm 3 /r  Working pressure  25Mpa  Hydraulic motor

 SlewFixed displacement axial piston motor  Travel  Variable displacement axial piston motors  Performance  Slew speed  12 rpm  Min. back slew radius  1650 mm  Max. travel speed high/low  4.8/2.6km/h  Grade ability  35 °  Traction force  46.3kn  Max. digging force of bucket  44.5kn  Max. digging force arm  30.7kn  Ground pressure  0.337kg/cm 2  Tank capacity   Fuel tank capacity  135L  Hydraulic tank capacity  95.8L  8ton Crawler Excavator with CE Approved CT80-7b
