• Model NO.：HB40
• Vibrating Amplitude：2.6mm
• Certification：ISO9001: 2000, CE
• Condition：New
• Color：Yellow
• Transport Package：Cartons
• Trademark：top brand
• Origin：China
• HS Code：8429521200
• Production Capacity：500000

TravelCategoryItemUnitParameter ChassisModel FMManufacturer volvMax. speedkm/h90.8Max. gradeability 34.70%Min. turning diameterm18.4Brake distancem≤7Wheelbasemm4900+1370Tread (front/rear)mm2019/1834Approach angle/departure angle.18/10Min. clearancemm270Tyre specification 12.00R20 EngineModel D13Output powerkw/(r/min)294/1400-1800Max. torqueN.m/(r/min)2000/1050-1400Displacementl12.8Emission Standard Nation III GB OthersDimension (Length×Width×Height)mm11180×2500×3990Total vehicle weightkg32600Fuel tank capacityl410Fuel consumption per 100kml/100km40Pumping operationPumping systemTheoretical output(high pressure/low pressure)m³/h70/140Concrete pumping pressure(high pressure/low pressure)Mpa11.8/6.38Theoretical pumping times(high pressure/low pressure)/min15/27Max. diameter of pumping concrete aggregate 40Feeding height 1450 Placing boomPumping slump range 12-23Reach height 39.8Reach depth 27.9Slewing radius 35.8Slewing angle 3701st boom stretch angle 902nd boom stretch angle 1803rd boom stretch angle 1804th boom stretch angle 2405th boom stretch angle 250Outrigger spanOverall outrigger span7800Front outrigger transverse span8350Rear outrigger transverse span7200
