• Model NO.：SWSCP500
• Certification：ISO9001: 2000
• Condition：New
• Curbstone Size：250X130cm
• Paving Radius：61 Cm
• Paving Speed：0-15 M,Min
• Operating Weight：11000kg
• Warranty：One Year
• Transport Package：Standard Export Packing
• Specification：ISO9001
• Trademark：SINOWAY
• Origin：China
• HS Code：84294990
• Production Capacity：200 Unit Per Year

Basic Info.

Model NO. SWSCP500 Certification ISO9001: 2000 Condition New Curbstone Size 250X130cm Paving Radius 61 Cm Paving Speed 0-15 M/Min Operating Weight 11000kg Warranty One Year Transport Package Standard Export Packing Specification ISO9001 Trademark SINOWAY Origin China HS Code 84294990 Production Capacity 200 Unit Per Year

Product Description

Main Features
The control system is simple and reliable by using advanced CAN communication technology;
The LCD clearly displays total working situation of the whole machine;
The console is easily operation and convenient for turning and disassembling;
The emergency switches located in main control box can make the paver continue to work in case console is out of work

Hydraulic System
US SAUER Variable Pump has advantages of energy saving and reducing temperature in hydraulic system;
US HYDRAFORCE valves is compact in structure and easy for repairing;
The hydraulic vibrators are made by US WYCO Company with stable performance.

Other Working Mechanism
The contractor could reduce positioning time with hydraulically offset mold and the paver could be used on any working situations.
The feeding auger can rotate, tilt and shift to make its exit right towards mould chutes;
The feeding auger and belts can rotate which make the machine easy to transport;
Right rear track can laterally move, so it is convenient to load and unload in the truck

Technical Data

Performance
Speed: Travel 0-32m/min; Paving 0-15m/min
Paving Radius: 610mm
Paving Width: 1800mm
Paving Height: 1200mm

Transportation
Dimension (L*W*H): 5250*2700**2650mm
Weight: 11000kg

Engine
Cummins B3.3, 60KW@2200rpm
Fuel tank: 115L

Automatic Control System
Automatic control on steering and leveling by precise electronic-over-hydraulic sensors; CAN communication between sensor and controller;

Hydraulic System
Hydraulic pump: One electronic controlled closed loop main pump and three open loop load sensed US SAUER variable displacement pumps;
Hydraulic oil cooler: Extra capacity forced air oil cooler;
Filter: Including inlet-suction, outlet-high pressure and oil-return filters;
Hydraulic oil tank: 190L

Hydraulic Vibrators
Type: Hydraulic powered, motor in head, variable speed, independently controlled
Quantity: Four hydraulic circuits and two hydraulic vibrators with mounts;

Material Feeding Auger
Driven: Auger is directly driven by hydraulic motor, with reliable performance and high torque;
Dimension: 4500MM Length and 420mm diameter
Installation: It can be rotated and shifted by hydraulic cylinders and easily to receive concrete from the ready-mix truck.

Water System
Type: High-Pressure washer with 15Mpa water pressure
Capacity: 290L

Track System
Type: Three hydraulic powered track
Track dimension: 1630*300*610mm

Options
Two additional vibrator circuits
Additional vibrators and mounts
Belt conveyor
Hydraulic front-grade control and mount
Light Kit
Stringline Kit
Spare parts kit


Technical Documents & Product Certificate	One set of technical documents in English or in Chinese & English including operator's manual and parts book for the machine, operator's manual and parts book for the engine, and one set of manufacturer's certificate shall be shipped with the good.
Commissioning and training	Upon request, we shall send our service engineer for commissioning and training of your operator and other staff for one week. Buyer will provide international round ticket, suitable accommodation, food, local transportation and USD100 per day salary to our service engineer.
Guarantee:	The Seller promise that the good thereof is made of the best materials with first class workmanship, brand new and unused, and complies in all respects with the quality, performance and specifications stipulated in the contract. When the good is normally installed, operated and repaired, the limited warranty will be 12 months or 1,500 operational hours which occurs first from the date of delivery from bill of lading.
