Hot Sale Mini Skid Steer Loader Mini Crawler Loader Ts100
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Certification：CE, ISO9001: 2000
- Condition：New
- Transmission：Hydraulic - Mechanical Transmission
- Walking Mode：Wheeled
- Type：Small Loader
- Rated Operating Capacity(Kg)：1500
Base Info
- Model NO.：TS100
- Bucket Capacity：0.6-0.7
- Operationg Weight(Kg)：4280
- Max. Travel Speed(Km/H)：10,20
- Fuel Tank Capacity(L)：85
- Overall Dimensions(mm)：3385X1850X2025
- Maker/Model：Cummins 4BTA3.9-C100
- Max Lifting Force：100HP,2500rpm
- Usage：Special Type
- Engine Power：<74kw
- Transport Package：Container or RO-RO or Bulk Ship
- Specification：ISO, CE
- Trademark：luyue
- Origin：Shandong
- HS Code：8429510000
- Production Capacity：50000PCS,Year
Description
Basic Info.
Model NO. TS100 Bucket Capacity 0.6-0.7 Operationg Weight(Kg) 4280 Max. Travel Speed(Km/H) 10/20 Fuel Tank Capacity(L) 85 Overall Dimensions(mm) 3385X1850X2025 Maker/Model Cummins 4BTA3.9-C100 Max Lifting Force 100HP/2500rpm Usage Special Type Engine Power <74kw Transport Package Container or RO-RO or Bulk Ship Specification ISO, CE Trademark luyue Origin Shandong HS Code 8429510000 Production Capacity 50000PCS/YearProduct Description
Hot Sale Mini Skid Steer Loader Mini Crawler Loader Ts100| TS100 |
| Specifications |
| Rated operating capacity(kg) 1500 |
| Tipping load(kg) 3000 |
| Bucket capacity(m3) 0.6-0.7 |
| Operationg weight(kg) 4280 |
| Max. travel speed(km/h) 8-16 |
| Hydraulic pump flow(L/min) 75/130 |
| Fuel tank capacity(L) 85 |
| Overall dimensions(mm) 3385×1850×2025 |
| Dimensions |
| Height at maximum extension(mm) |
| Height to bucket hinge pin(mm) 2920 |
| Width with bucket(mm) 1850 |
| (mm) 320 |
| (mm) 1500 |
| Ground clearance(mm) 200 |
| Engine |
| Maker/Model CUMMINS 4BTA3.9-C100Net power 100hp/2500rpm |
| Type |
| 4 Cylinder in-line, Water cooled, 4 stroke, |
| Diesel engine |
| Displacement(L) 3.9-4.2 |
| Standard |
| Open-type operator cab |
| ()Hydraulic joystick controls |
| Standard bucket |
| Auxiliary hydraulic couplers |
