Hot Sale G9220 Motor Grader, Sdlg 220HP Grader, Good Price
Shandong Weiyang Construction Machinery Co., Ltd.- Certification：ISO, CE
- Condition：New
- Application：Railway, Mine, Farmland, Highway
- Transmission：Power
- Walking Mode：Wheeled
- Type：Medium-sized Grader
Base Info
- Model NO.：G9220
- Transport Package：40hq Container
- Specification：220HP
- Trademark：SDLG
- Origin：China
- HS Code：8429209000
- Production Capacity：200,Month
Description
Basic Info.
Model NO. G9220 Transport Package 40hq Container Specification 220HP Trademark SDLG Origin China HS Code 8429209000 Production Capacity 200/MonthProduct Description
G9220 SDLG grader is a high-speed,high efficiency,high presision and versatile product developed by SDLG after full investigation of market demands,which can complete the ground leveling and trenching,slope scraping,bulldozing,snow discharge,loosing,compaction,material distribution,mixing,etc..,and is widely used in highways,airports,defense engineering,mine construction,road construction,water conservancy construction,farmland improvement and other construction conditions.| Item | Specifications |
| Operation mass of complete machine | 16500kg |
| Dimensions(LXHXH) | 9235X2710X3240MM |
| Max.angle of inclination of front wheel | ±18° |
| Max.swing angle of front wheel | ±16° |
| Max.steering angle of front wheel | ±50° |
| Steering angle of frame articulation | ±23° |
| Cutter diameter | 1626mm |
| Cutter specifications(LXHXT) | 4267X635X25mm |
| Rotation angle of balde | 360° |
| Ground clearance of balde | 445mm |
| Cutting depth of blade | 787mm |
| Sliding range of balde | 673mm |
| Max.traction(f=0.75) | 87kn |
| Engine power | 165kw |
| Max.speed(forwader/backwarder) | 39/25.5km/h |
Contact information:
Tyson
General Manager
Shandong Weiyang Construction Machinery CO.,LTD
One professional supplier for wheel loader,road roller,excavators and so on
Tel:+86 539 8785953 Fax:+86 539 8180953 Mobile:0086 13953989059
Website: shandongweiyang.en.made-in-china.com
