Dfm Factory High Quality 4 Ton Single Drum Vibratory Road Roller/Compactor (YSW 204) for Sale with New Produced
Define Machinery Corp.- After-sales Service：1 Year
- Warranty：1 Year
- Type：Road Roller
- Working Method：Vibration
- Axle：Biaxial Dual-Drum
- Grinding Wheel Type：Tire Grind
Base Info
- Model NO.：DFM-YSW204
- Compaction Depth：35cm
- Engine Type：Diesel Engine
- Travel Speed：1.8,6.3 Km,H
- Certification：CE
- Condition：New
- Transport Package：Nude
- Specification：4030*1400*2450mm
- Trademark：DFM
- Origin：Luoyang City, China
- HS Code：8429401900
- Production Capacity：6000 Units,Year
Description
Overview
Product Description
Product Parameters
| Model | unit | YSW204 |
| Operating mass | kg | 4000 |
| Static linear load | N/cm | 140 |
| Working speed | km/h | 1.8/6.3 |
| Grade Capability | % | 35 |
| Min. turning radius | mm | 4500 |
| Min. ground clearance | mm | 310 |
| Wheelbase | mm | 2230 |
| Steering angle | ° | ±20 |
| Sway angle | ° | ±5 |
| Vibration frequency | Hz | 50 |
| Nominal amplitude | mm | 0.5 |
| Centrifugal force (high frequency/low frequency) | kN | 60 |
| Drum diameter | mm | 1000 |
| Drum width | mm | 1270 |
| Engine Model | CHANGCHAI ZN490B | |
| Rated power | KW | 36 |
| Rated speed | r/min | 2400 |
| Dimension | mm | 4030*1400*2450 |
