• Model NO.：SWMH250L
• Size：Medium-Sized
• Certification：ISO9001: 2000, ISO14001
• Condition：New
• Working Radius：10.2 M
• Max. Lifting Height：11.3 M
• Engine Power：260HP
• Operating Weight：25ton
• Warranty：One Year
• Transport Package：Nude
• Specification：ISO
• Trademark：SINOWAY
• Origin：China
• HS Code：84314990
• Production Capacity：200 PCS Per Year

Basic Info.

Model NO. SWMH250L Size Medium-Sized Certification ISO9001: 2000, ISO14001 Condition New Working Radius 10.2 M Max. Lifting Height 11.3 M Engine Power 260HP Operating Weight 25ton Warranty One Year Transport Package Nude Specification ISO Trademark SINOWAY Origin China HS Code 84314990 Production Capacity 200 PCS Per Year

Product Description

Product Features

1-Dual engine ( Electric motor + Diesel engine) more environmental protection;
2-Electric operation has over-current and heat leakage protection device;
3-Utomatic identification of phase sequence to prevent reverse rotation of oil pump;
4-Hydraulic system power-off, oil self-locking protection device;
5-Multiple compound movements during operation to improve efficiency;
6-The hydraulic system is equipped with air-cooled radiator;
7-The gripper can rotate and change direction automatically 360 degrees;
8-When electric operation is carried out in the upper control room, there is a dual-purpose air conditioner for heating and cooling;
9- Hydraulic Cabin elevatied.

Machine Show





Specifications

Dimensions
Overall length	15350mm
Overall height	3620mm
Overall width	3260mm
Wheelbase	3200mm
The maximum lifting height of driving cab	5320mm
Tail slewing radius	4122mm
Gap between rotary table and ground	1519mm
Width of platform	627mm
Power
Engine	132kw
Electric Motor	75kw
Fuel tank	295L
Walking System
Walking speed	15km/h
Max.tranction force	110KN
Gradeability	15%
Hydraulic System
Max.flow	2*160L/min
Max.working pressure	28Mpa
Hydraulic oil tank	420L
Pilot pressure	3.6Mpa
Main Performance Parameters
Total weight	35t
Max.Lifting moment	100t.m
Max.swing speed	3.6r/min
Max.swing torque	51KN.m
