• Model NO.：HB37A
• Productivity：150m²,h
• Feeding Height：3700mm
• Condition：New
• Color：Yellow
• Max. Speed：90km,H
• Min. Turning Diameter：18.4m
• Brake Distance：7m
• Chassis Model：Cxz51q ( Japan )
• Total Weight：28150kg
• Reach Depth：23.7m
• Max. Delivery Pressure：8.7,13MPa
• Max. Engine Power：287kw
• Specification：11990*2490*3900mm
• Origin：China
• HS Code：8501109190
• Production Capacity：200

Travel OperationCategoryItemsUnitParameters

Chassis











   Make  Max.speedkm/h 90.8Max.gradeability 34.70%Min.turning diameterm18.788Brake distancem≤7Axle basemm4900+1370Wheelbase (front/rear)mm2019/1834Approach/departure angle°18th.OctMin.ground clearancemm270Tire 12.00R20

Engine





  Model D13Output powerkw/(r/min)294/1400-1800Max.torqueN.m/(r/min)2000/1050-1400DisplacementL12.8Emission standard ChinaIII   GBIII

Others





Dimension (L×W×H)mm11990×2500×3900Overall weightkg28400Fuel tank volumeL410Fuel consumption (100km)L/100km40Product Show
